DES-1016D Fast Ethernet Switch User’s Guide
4
Desktop or Shelf Installation
When installing the Switch on a desktop or shelf, the rubber feet included with the Switch should
first be attached. Attach these cushioning feet on the bottom at each corner of the device. Allow
enough ventilation space between the Switch and any other objects in the vicinity.
Figure 2-1 DES-1016D Switch installed on a desktop or shelf
Wall Installation
The Switch can be mounted on a wall. First, drill two pilot holes in the desired location. Next,
insert the screw anchors and screws (as shown in the figure below).
Figure 2.2 Preparations for mounting the Switch on a wall
