SoundMax SM-CDM1042 - Manual (Page 37)

37
Specification
General
Power supply
12 V DC
Current consumption max. 15 A
Maximum power output 50 Wx4 channels
Fuse 15 A
Dimensions (L x W x H) 178 x 50 x 160 mm
Supported storages D/CD-R/CD-RW/USB/SD/MMC
FM stereo radio
Frequency range
87.5 - 108.0 MHz
Usable sensitivity 4 V
I.F. Frequency 10.7 MHz
Storable stations 18
MW Section
Frequency range
522 kHz – 1620 kHz
I.F. Frequency 450 kHz
Storable stations 12
Disc player
System:
Compact disc audio system
Frequency response 40 Hz – 18 Hz
Signal to noise CD 55 dB
Number of channels 2 stereo
Line out CD max 2000 mV
Specifications are subject to change without notice. Dimensions are approximate.
