35
5. Video/audio output
You can use the “video/audio out” on the digital video camera to output the video/audio to an
external device (such as: TV), the method is as below:
● Step one: Connect the smaller end of the USB cable to the USB connector port of the video
camera. Insert the the yellow and white plug of the USB cable to the video input
of the TV port.
● Step two: Switch the TV to the correct channel.
● If the TV standard is not correct, you can switch to the appropriate standards
1. Enter the “camera setup” page.
2. Use the up button ▲ and down button ▼ to select “video out”.
3. Then use the up button ▲ and down button ▼ to select NTSC or PAL standards and
press the confirm button .
Note: Different TV manufacturers will have different broadcast channels, please refer to
the TV’s user manual.
