CONTENTS OF HARDWARE PACK
Remove this sheet from your owner’s manual and lay the hardware on the illustration for identification purposes.
After assembly, keep the Slope Gauge which is on the reverse side of this sheet for future use.
(Hardware pack may contain extra items which are not used on your unit.)
ATTACHfNG THE
LOWER HANDLE
Hairpin
Clips
ATTACHING THE
UPPER HANDLE
Curved Head-
Bolts
Split Washers-
5/16" I.D.
Hex Nuts
5/16-18 Thread.
Phillips
Head
Screws
ATTACHING THE DRIVE CLUTCH CONTROL
CABLE
Plastic-
Cap
ATTACHING THE BLADE
BRAKE/CLUTCH CABLE
Push Cap
Upper
Handle
Drive
Clutch
Housing
Blade Brake/Clutch
Control Handle
-Throttle Control
Housing
^_^Lower Handle
Catcher
Panel
PARTS INFORMATION
o
c
>
o
3
(Q
W
ASSEMBLY OF GRASS CATCHER
(Upper Bag Support
Is Not Shown)
Truss Machine-
Self-Tapping Screws
Q[ FINAL
ASSEMBLY
Hub Caps are
Not Shown
SECURING THE CABLES
