Bolens TMO-37478A - Manual (Page 20)

TMO-37478A
4 H.P. 21" ROTARY MOWER
PARTS LIST FOR MODEL TMO-37478A (CONTINUED)
REF.
NO.
PART
NO.
DESCRIPTION
NEW
PART
—
REF.
NO.
PART
NO.
DESCRIPTION
-------- i
NEW
PART
106 711-0313 Sleeve .526" I.D. x .690" 133 16559CC621 Side Chute Deflector Ass'y.
O.D, X .880" Lg. 135 753-0431 Kit—Control Housing Comp.
107 732-0397 Ext. Spring 1.75" Lg. 136 10622 Spring—Nylon
108 714-0104 Intern. Cotter Pin 5/16" Dia. 137 17176 Engine Mounting Plate Cover
109 732-0482 Extension Spring .50" O.D, 138 17053 Chain Cover
X 3.20" Lg. 140 710-0599 Hex Wash. S-Tap Scr. V4-20
110 14309 Clutch Housing X .50" Lg.
111 736-0221 Intern. L-Wash. 3/8 I.D.' 142 736-0326 FI-Wash. .510" I.D. x 1.0"
112 738-0705 Shid. Bolt .623" Dia. x .425 O.D.
113 734-1511 Front-Wheel Ass’y. Comp. 143 741-0522 Hex Flange Brg. .506" t.D. N
7 x 2,0" N
144 736-0300 FI-Wash. .385" I.D. x .87"
114 731-0617 Self-Propelled Control Cover O.D.
115 731-0618 Self-Propelled Control Cover 147 738-0719 Rear Shaft Ass’y, 21.94" Lg.
116 731-0620 Control Lever 148 741-0324 Hex Flange Bearing .506"
117 720-0190 Door Grip I.D. Plastic
118 710-0841 FI-“C’’-Sunk Hd. Tap Scr. 149 736-0160 FI-Wash. .531" I.D. x .930"
#10 X .75" Lg. O.D.
121 710-0671 Curved Carr. Bolt 5/16-18 x 150 736-0179 FI-Wash. .531" I.D. x 1.25"
1.38" Lg. O.D,
122 756-0504 Fixed Pulley Adapter 151 741-0491 Flanged Nyliner Brg.
123 736-0409 Serrated Washer 1.0" t.D. 152 710-0751 Hex Bolt 1/4-20 x .62" Lg.
124 756-0503 Serrated Pulley Half (Grade 5)
125 736-0408 Wave Washer 1.005" t.D. 153 717-0417 Transmission Comp.
126 710-0618 Flat HD Tap Scr. V4-20 x (See Breakdown)
.625" Lg.
154 16500 Hex Bearing Cup
127 748-0319 Flywheel 155 726-0245 Push Cap
128 748-0320 Flywheel Adapter 156 726-0135 Push Cap
129 746-0406 Control Cable—49" Lg. 157 717-0845 Blade Brake Clutch Ass’y.
130 748-0318 Ratchet Wheel 1.62" O.D. Comp.
131 714-0115 Cotter Pin 1/8" Dia. x 1.00"
f-g.’
'Common Hardware—May be purchased locally.
IMPORTANT; DO NOT order parts by reference
number (Ref. No.).
NOTE; Specifications subject to change without notice
or obligation.
Part No. Description
8176B088-8
788-0621
777-7002
770-6474C Hardware Pack
Brilliant Fire Mist Spray Paint
Montgomery Ward Plastic Logo
Operating Manual
20
