CONTENTS OF HARDWARE PACK
Hardware pack may contain extra items which are not used on your unit. Part numbers are shown in parentheses.)
A
ATTACHING THE DECK LINKS
Co^
■mDD
Eyebolts
(711-0817)
(Not Shown to
Scale) Quantity 3
Hex Nuts
1/2-13 Thread
(712-0206) Quantity 3
C
ATTACHING THE DECK WHEELS
(If not already attached)
rr^quu
(46" Deck
Only)
Deck
Wheels are
Not Shown
Front
Axle Bolts
3-1/4"
----- Long
B
ATTACHING THE CUTTING DECK
(738-3056)
Flat Washers
1/2" I.D.
(736-0192)
Cupped
Washers
3/8" I.D.
(736-0105)
Rear
Axle Bolts
2-1/4" Long
(738-0533)
Clevis Pin
(711-0701)
Small
Hairpin
Clip
(714-0104)
Flat
Washers
1/2" I.D.
(736-0192)
NOTE: This
hardware may
be assembled
to the deck
Spacers
(750-0932A)
Hairpin Clips
(714-0101)
Lock
Washers
3/8" I.D.
(736-0169)
Hex Nuts
3/8-16 —
Thread
(712-0798)
