Models 074 and 084
PARTS LIST FOR
0 7 2 >
T5>'B>c
lH(o- OЦOЭ~-
^ t£l_\_ovx)
'
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
14589
Front Baffle 20" (Optional)
38
09966
Hand Knob (Cptional)
14554
Front Baffle 22" (Optional)
39
712-0267
Hex Nut 5/16-18 Thd.*
2
718-0145
Grip
40
736-0119
L-Wash. 5/16" I.D.*
3
* *
Hub Cap
41
720-0190
Spring Lever Knob
4
734-0661
8" Wheel Ass’y- Comp.
42
732-0401
Lock Cut Spring
734-0876
7" Wheel Ass’y- Comp.
43
710-0818
Hex Cent. L- Bolt 3/8-24
5
741-0262
Flange Brg.—Plastic Vz" I.D.
X
2.00" Lg.
6
742-0220
20" Blade (074)
44
711-0719
Lock Pin .75" Dia. x 1.80
742-0222
22" Blade (084)
45
712-0328
Special Hex Nut 5/16-24 Thd.
7
746-0473
Throttle Control Wire—39"
46
717-0482
Blade Brake Clutch Ass’y.
8
749-0373
Lower Handle (Chrome)
Comp.
749-0372
Lower Handle (Painted)
47
14300
Clutch Blade Housing Ass’y.
9
—
Engine
48
732-0396
Comp. Spring ,35" C.D. x
10
751-0333
Casing Clamp
2.00" Lg.
11
710-0429
Hex B-Tap Scr. #10 x .38" Lg
49
741-0124
Ball Brg. .669" I.D. x 1.574"
12
12935
Handle Mount Brkt. Ass’y.—
C.D.
LH.
50
14304
Clutching Cone
12936
Handle Mount Brkt. Ass’y.—
51
14305
Brake Cup Cone
R.H. (Not Shown)
52
14306
Clutch Housing
13
710-0603
Hex Wash. Hd. B-Tap Scr.
53
710-0875
Hex Wash. TT-Tap Cl.-Scr.
5/16-18
X
.50" Lg.
1
/
4-20
X
.75" Lg.
N
14
14531
Retaining Strip
54
719-0256
Fan Adapter
15
710-0258
Hex Bolt 1/4-20
X
.62" Lg.*
55
731-0520
Ball Block
16
712-0271
Hex Sems Nut i/4-20 Thd.*
56
732-0397
Extension Spring .35" C.D. x
17
731-0575
Rear Flap Ass’y.
1.75" Lg.
18
14578
Height Adj. Ass’y.—R.H.
57
736-0333
FI-Wash. .690" I.D. x 1.060"
14579
Height Adj. Ass’y.—L.H.
C.D.
(Not Shown)
58
741-0326
Steel Ball .500" Dia.
19
15261
Height Adj. Plate
59
746-0402
Clutch Cable—
MV
20
15262
Pivot Bar
60
736-0105
Bell-Wash. .400" I.D. x .88"
21
14832
Spring Lever w/Knob
C.D.
22
738-0507
Shid. Bolt .500" Dia. x .375
61
736-0169
L-Wash. 3/8" I.D.*
23
712-0798
Hex Nut 3/8-16 Thd.*
62
726-0219
Snap Cn Scr. #8 x .38 Tap
24
736-0331
Bell-Wash. .39" I.D. x 1.13"
63
731-0634
Engine Shroud Ass’y.
C.D.
64
736-0105
Bell-Wash. .400" I.D. x .88"
25
14944
Chute Deflector Ass’y. Comp,
N
C.D.
26
11143
Deflector Hinge Plate
65
738-0102
ShId. Bolt .498" Dia. x 1.450
27
711-0555
Pivot Pin
66
710-0796
Truss Mach. Hi-B Tap Scr.
28
726-0106
Cap Speed Nut V
4
" Rod
#12
X
1.50" Lg.
29
732-0253
Torsion Spring
67
726-0135
Cap Speed Nut 5/16" Rod
30
710-0289
Hex Bolt
1
/
4-20
X
.50" Lg.*
68
731-0523
Control Panel Half
31
712-0287
Hex Nut
1
/
4-20
Thd.*
69
731-0524
Control Disc Pin
32
736-0329
L-Wash.
1
/
4
" l.D.;^
70
731-0526
Ciutch Panel Half
33
14995
20" Deck Ass’y.
N
71
731-0528
Throttle Control Lever
14998
22" Deck Ass’y.
72
749-0536
Upper Handle (Chrome)
34
710-0654
Hex Wash. Hd. TT-Tap Scr.
749-0538
Upper Handle (Painted)
3/8-16
X
1.00" Lg.
73
731-0610
Control Handle Ass’y.—R.H.
35
714-0104
Intern. Cot. Pin 5/16" Dia.
36
726-0192
Cable Tie
37
710-0671
Curved Carriage Bolt 5/16-18
X
1.38" Lg.
710-0405
Curved Carriage Bolt 5/16-18
X
1.75" Lg. (Cptional)
*For faster service obtain standard nuts, bolts and washers
locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list.
(462—Red Flake)
When ordering parts, if color or finish is important use the ap
propriate color code shown above, (e.g. Red Flake
Finish —10292 (462).)
15
NOTE: The engine is not under warranty by
the mower manufacturer. .. If repairs or
service is needed on the engine, please
contact your nearest author-
a
—^—-—■
ized engine service outlet. Find It Fast
Check the “Yellow Pages” of In The
your telephone book under Yellow Pages
“Engines—Gasoline.”
