MODEL 650
PARTS LIST FOR MODEL 650 SHREDDER
Ref.
No.
Part
No.
Color
Code
DESCRIPTION
New
Part
Ref.
No.
Part
No.
Color
Code
DESCRIPTION
New
Part
1
11476 -452
Door-Chip-lt
32
736-0192
FI-Wash. .531" I.D. x.937 O.D
2
710-0465
Hex Bolt 1/2-20x4.50" Lg.*
X
.09
3
711-0580
Clevis Pin
33
11459
Flail
4
711-0579
Flail Spacer 7/32" Lg.
34
711-0564
Flail Spacer 23/32" Lg.
5
11455-488
Cutting Finger
35
711-0578
Clevis Pin .50" Dia. x 3.0" Lg.
6
736-0921
L-Wash. 1/2" Scr.*
36
736-0247
Fl.-Wash. .406" I.D. x 1.25"
7
726-0111
Palnut 3/16" Dia.
O.D. Hdn.
8
712-0922
Hex Jam Nut 1/2-20 Thd.*
37
736-0217
L-Wash. 3/8" Scr. H.D.
9
714-0507
Cotter Pin 3/32" Dia. x 3/4"
38
710-0151
Hex Bolt 3/8-24
X
2.00" Lg.
Lg.*
H.T.
10
11465 -452
Chute Deflector
39
14575 -488
Flail Housing Ass'y- -Comp.
N
11
712-0107
L-Nut 1/4-20 Thd.
40
712-0107
Hex Cent. L-Nut 1/4-20 Thd.
12
710-0289
Hex Bolt 1/4-20
X .
50" Lg.*
41
11477 -452
Upper Guide Extension Ass'y.
13
714-0114
Sq. Key 1/4"
X
2.00" Lg.*
42
11478
Hinge Pin
14
13430 -452
Impeller Assembly
43
726-0111
Palnut 3/16" Dia.
15
710-0157
Hex Bolt 5/16-24x3/4" Lg.*
44
712-0109
Wing Nut Elastic 1/4-20 Thd.
16
736-0119
L-Wash. 5/16" Scr.*
45
13431 -452
Blade
17
14573 -452
Hopper to Engine Mtg. Plate
N
46
11460 -488
Guide Extension Assembly
18
Engine
47
11472 -488
Guide Extension
19
11464-488
Engine Mounting Plate
48
736-0264
FI-Wash. 5/16" Scr.*
20
712-0123
Hex Nut 5/16-24 Thd.*
49
11481 -488
Hopper Assembly
21
736-0119
L-Wash. 5/16" Scr.*
50
710-0601
Hex Wash. Hd. Self-Tap Scr.
22
738-0521
Shaft
5/16-18
X
.50" Lg.
24
726-0221
Push Cap
51
11479
Clamp Rod Assembly
25
711-0494
Spacer
52
11454 -452
Back-up Plate
26
734-1056
Wheel Ass'y- - Comp.
N
53
11467 -488
Inlet Guide Assembly
27
736-0100
FI-Wash. .50" I.D.*
54
09966
Knob Ass'y.
28
710-0624
Hex Bolt 5/16-24
X
1.50" Lg.*
55
11480
Stop Washer
29
712-0429
Elastic Stopnut 5/16-18 Thd.
56
711-0566
Chute Pivot Rod
30
710-0237
Hex Bolt 5/16-24
X .
62" Lg.*
764-0126
Bag (Not Shown)
31
714-0144
Cotter Pin 1/8" Dia. x 1.00"
Lg.* (Special)
{497 - Yard-Man Red)
(488 - Mack Truck Yellow)
When ordering parts, if color or finish is important use the ap
propriate color code shown above (e.g. Mack Truck Yellow
Finish—11907(488).)
‘For faster service obtain standard nuts, bolts and washers
locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list.
The engine is not under warranty by the shredder manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the “Yellow Pages” of
your telephone book under “Engines—Gasoline.”
