Drawing No. 79216
EXPLODED VIEW — V-TWIN ENGINE PARTS
ITEM
PART NO.
QTY.
DESCRIPTION
ITEM
PART NO.
QTY.
DESCRIPTION
1
69331
1
CYLINDER ASSEMBLY
36
67158
4
BOLT, INTAKE
2
69333
1
SLEEVE BEARING-30 DIA.
MANIFOLD MNT.
3
67805
1
OIL SEAL-30 DIAMETER
37
68574
1
PIPE-PLUG, 1/8" NPT
4
79234
1
CYLINDER HEAD
38
68554
1
SEAL, GOV. SHAFT
ASSEM.-NO. 1
39
68573
1
0-RING, OIL PUMP
5 ,
79235
1
CYLINDER HEAD
40
70506
1
0-RING, OIL GALLEY
ASSEM.-NO. 2
41
70554
1
SPACER, CARBURETOR
6
70169
4
SEALING WASHER
42
70568
4
STUD, ROCKER ARM
7
69332
2
GASKET-CYLINDER HD.
43
75253
4
SEAL, WASHER
8
72301
1
BREATHER ASSEMBLY
-VALVE COVER
9
72315
1 .
GASKET, BREATHER
44
67885
4
NUT, NYLOK-M6
10
70190
1
SCREW, BREATHER
45
75254
4
SCREW, VALVE ADJUST
11
70596
1
TUBE, BREATHER
46
70535
1
SCREEN, OIL
12
69336
1
GASKET, OIL SUMP
47
75255
1
STARTER MOTOR
13
69325
8
BOLT, CYLINDER HEAD
48
75256
2
BOLT, STARTER MOTOR
14
67888
2
PLUG, OIL DRAIN-3/8" NPT
73
68572
2
SCREW, OIL PUMP
15
72334
1
CRANKSHAFT ASSM.
74
75272
2
TERMINAL, SPARK PLUG
16
75247
1
OIL SUMP ASSEMBLY
75
70122
2
SEAL, VALVE STEM
17
67924
1
OIL SEAL-35 DIAMETER
76
67910
2
SEAT, INTAKE VALVE
18
67878
9
BOLT, OIL SUMP
77
67911
2
SEAT, EXHAUST VALVE
19
75248
2
PISTON ASSM.-STANDARD
78
67813
4
VALVE, GUIDE
20
75249
2
RING SET- PISTON
79
75268
1
RETAINER AND PIN
-STANDARD
80
75270
1
ROLL PIN
21
69327
4
LOCKING RING, PISTON
81
70592
1
AIR CLEANER BASE
22
75250
2
PISTON PIN-STANDARD
82
73123
1
AIR FILTER
23
75251
2
CONNECTING ROD ASSM.
(FLAME RETARDENT)
24
72346
4
BOLT, CONNECTING ROD
83
70593
1
COVER, AIR CLEANER
25
69316
2
EXHAUST VALVE
84
72300
1
SCREW, AIR CLEANER
26
69317
2
INTAKE VALVE
COVER
27
67816
4
VALVE SPRING
85
67156
2
SCREW, AIR CLEANER
28
69320
4
RETAINER, VALVE SPRING
BASE
29
70513
4
KEEPER, VALVE
86
69341
1
PRE-FILTER
30
70584
4
TAPPET, VALVE
87
80011
1
SPRING. BRUSH SET
31
70530
1
CAMSHAFT ASSEMBLY
88
70597
1
TUBE, AIR INLET
32
72358
1
INTAKE MANIFOLD
89
69358
1
DEFLECTOR-BREATHER
33
69379
2
GASKET, CARB. MNTG.
90
67920
2
GASKET, VALVE COVER
34
67895
2
GASKET, INTAKE
91
69328
1
ROCKER ARM COVER
MANIFOLD
92
70547
1
OIL PUMP ASSEMBLY
35
70594
2
BOLT, CARB. MNTG.
■23
—
