REPAIR PARTS — BASE & PULLEYS
Drawing No. 98739
ITEM
PART NO.
QTY.
DESCRIPTION
ITEM
PART NO.
QTY.
DESCRIPTION
1
86318
1
BASE, MOUNTING
45
67871
1
0-RING, CAP
2
68527
2
HHCS-M6-1.0X20LG
46
75712
1
0-RING, DRAIN
3
46911
4
MOUNT, (RUBBER)
47
75711
1
PIPE, OIL DRAIN ADAPTOR
4
25017
8
CAPSCREW, HEX HD.-
50
43790
1
ELBOW-3/8'NPTX 3/8”
3/8"-16x1/2*
51
47290
1
HOSE, 3/8 XI0-1/2”
5
22237
8
LOCKWASHER, M10
52
35461
1
FITTING, B/VRBED -1/4” NPT
6
22129
4
LOCKWASHER-M8
53
69811
1
CAP, HEX-1/4” NPT
.-..SIf:iD.,^RUaB.EBilVID.U.NJ».^
54
65852
1
CUP, HOSE RETAINER
8
77603
2
HHCS-5/16-18X3.5SPC
55
81105
2
NUT, FLANGE 5/16-18 LOCK
9
22259
2
NUT, HEX-5/16-18
56
73179
1
OIL FILTER SUPPORT
10
52858
6
NUT, FLANGED LOCK-M8-1.25 57
70185
1
FILTER, OIL
11
51730
2
CAPSCR. HEX HD.,
58
60108
1
10 PSI OIL PRES. SWITCH
M8-1.25X60MM
59
74948
3
FITTING-5/16"
12
29459
2
SPRING, BELT TENSION
60
74950
1
TUBE, OUTER OIL
13
75215
2
WASHER, SPRING CNTR
61
74951
1
TUBE, INNER OIL
14
73146
4
SLIDE (NYLON)
62
73134
1
ADAPTOR, OIL PAD
15
75209
2
SUPPORT, NYLON SLIDE
63
38750
3
CAPSCREW, HEX HEAD-
16
73174
1
MANIFOLD, EXHAUST
M6-1.00X30MM
17
79678
2
GASKET, EXHAUST
64
74949
1
FITTING, 90-DEGREE-5/16"
MANIFOLD
65
68548
1
GASKET, OIL PAD
18
55173
4
CAPSCR., HEXHD.-M8-1.25
66
62684
1
LUG, GROUNDING
X20MM (GRADE 10.9)
67
29289
-
TAPE, FOAM-1/16" THICK x 8'
19
72383
2
GASKET, COLLECTOR PAN
69
75281
1
SWITCH, HIGH TEMP,
21
75224E
1
PULLEY, ENGINE-5.2
70
74027
2
SCREW, PAN HEAD-M3-0.50
75224F
1
PULLEY, ENGINE-6.6
71
43182
2
LOCKWASHER-M3
75224G
1
PULLEY, ENGINE-7.2
73
75237
4
WASHER, SPRING RETAINER
22
73106E
1
PULLEY, ALT.-5.2
74
77681
1
CAP, VINYL-LOS-2 WIRE
73106F
1
PULLEY, ALT.-6.6
75
75474
1
CAP, VINYL-17D x 42L X 2H
73106G
1
PULLEY, ALT.-7.2
76
90800
1
ELBOW, EXHAUST
23
75216
1
BELT (POLY V 4L)-40“
- UNIVERSAL
24
49451
1
WASHER, PULLEY
77
94670
1
CLAMP, EXHAUST-1-1/8"
25
42633
1
CAPSCR., SOCKET HD.
78
75226
1
COVER, AIR
3/8”-24 X 1 (GRADE 5)
79
56893
23
SCREW (CRIMPTITE)
26
77017
1
GUIDE, BLOWER HOUSING
NO. 10-24
X
1/2" LONG
27
73118
1
CAPSCR., HEX HD.
80
75229
1
GASKET, SLIDE PAN
3/8”-24 X 2-1/4"
81
75227
1
SLIDE PAN
28
74906
11
SCREW (TAPTITE)
82
79246
4
CAPSCREW, HEX HEAD
M6-1.00X20
M6-1.00X 16MM WITH
29
74908
1
SCREW (TAPTITE)
LOCK WASHER
M5-0.80X10
83
22473
4
FLATWASHER, M6
30
72375
1
HOUSING, BLOWER
85
72384C
1
COVER, EXHAUST OUTLET
31
73185
1
SPACER, BLOW. HOUSING
87
77643
1
GASKET, EXHAUST OUTLET
32
22097
2
LOCKWASHER, M6
90
22447
1
LOCK WASHER-M6,
33
77682
1
CAPSCR. HEX HD.
TOOTHED
M5-0.80 X 80MM
91
91123
1
FUEL PUMP BRACKET
34
75242
4
SPRING, GENERATOR SET MT92
45756
5
M6X 10MM TAPTITE
35
49813
2
NUT, HEX M6X 1.0
SCREW
36
45757
2
CAPSCREW, HEX HD.,
93
87769
1
FUEL FILTER
M6-1.0X25LONG
94
87768
1
1/8” PIPE TO 1/4” TUBE
37
90859
1
COVER PLATE
FITTING
38
48031E
2
CLAMP, HOSE-3«”
95
87770
1
FUEL LINE
43
75710
1
TUBE, OIL RLL AND DRAIN
96
90088
1
VINYL COATED CLAMP
44
74958
1
CAP & DIPSTICK ASSEM.
97
90475
1
FUEL PUMP
—
