PARTS LIST »ALTERNATOR & FRAME
Item Part # Description Item Part# Description
1 BI87024GS CRADLE 57 66386GS ASSY, Brush Ho der
2 I94389GS SHIELD, Heat, Tank 58 66849GS SCREW
3 92982GS DECAL, Dan;^r 59 B487IGS COVER, Bearing Carrier
4 9266SGS INSULATION 60 74908GS SCREW
5 I93823GS ASSY,Tank, Fuel 62 66849CGS SCREW
6 B4363GS CAP, with Gauge, Fuel 63 65795GS RECTIFIER, Battery Charge
7 83000GS CLIP, Insulation 64 66449LGS BOLT, Stator
8 93826GS DECAL, Start Instructions 66 22097GS WASHER, Lock
9 78831BGS SCREW 74 I94034GS KIT, Fold Down Handle Hardware
10 83463GS GROMMET,Tank 77 I89302BGS ASSYWire
11 7739SGS NUT, Lock 78 77282GS SWITCH, Starter
12 I92980GS KIT, Valve Tank 79 I88987GS BRACKET, Switch
14 B2I53GS SCREW 80 I88989GS ASSY, Jack, DC
15 431I6GS SCREW 81 22287GS SCREW
17 73034GS DECAL, Fuel Shut-Off 82 22097GS WASHER, Lock
18 22I27GS NUT 83 96II3GS ASSYWire
19 778I6GS DECAL, Hot Muffler 84 I92985GS TRAY, Battery
20 83083GS SCREEN, Spark Arrestor 85 B4489GS BATTERY
21 86307GS SCREW 86 I89302CGS ASSYWire
22 92247GS HOUSING, Engine Adapter 87 I85939HGS ASSYWire
23 M9253IGS SUPPORT, Engine 88 I93347GS KIT, Battery Hardware
24 I89I60GS NUT 90 38359GS LUG
25 22I29GS WASHER, Lock 97 BI93200GS ASSY, Handle with Grip
26 828S7GS MOUNXVibration 98 I897I8GS GRIP
27 2233IGS SCREW 99 B4I35GS PIN, with L:an^rd
28 92609GS MOUNXVibration 100 22259GS NUT
29 22I42GS SCREW 101 22I29GS WASHER, Lock
30 A7433GS MUFFLER 102 498I3GS NUT
31 B9273IGS SUPPORT, Engine & Muffler 103 22I25GS WASHER, Lock
32 90239GS GASKET, Muffler 900 NSP ENGINE
33 BI342GS ASSY, Rotor
35 96796GS WASHER Parts Not Illustrated
36 4748IGS SCREW BB306IGS BOTTLE, Oil
37 BI897AGS ASSY, Stator B4767GS COVER, Storage
39 40976GS SCREW 72347GS PLUG, Spark
40 92332GS BRACKET, Muffler I897I3GS MANUAL, Owner's
41 66476GS SCREW 7311 IGS FILTER, Air
43 B4366GS ASSY, Contra Panel (see page 21) 84882GS WRENCH, Spark P ug
44 I94390GS SHIELD, Heat 43438GS PLUG, l20/240V,30A,4p
45 1433362IGS WIRE, Ground 70I85GS FILTER, Oi
46 I93646GS KIT, Grounding Hardware A8927GS MANUAL, Engine
48 8I9I7GS PIN,Rol B4I77GS CHARGER, Battery Float
49 B4986GS DECAL, Ground 65787GS CABLE, Battery Chartge
51 36893GS SCREW 37806GS PLUG, 120V, 30A
32 S4I32GS ASSY, Power Regulator I94033GS KIT, Decals
S3 67022GS GROMMET, Rubber
34 SRV66823DGS CARRIER, Rear Bearing Optional Accessories Not Included;
36 23762GS WASHER 84883GS Cord Wrap
