7500EXL Extended Life Generator
Id=lw^l=l=F±T-y
Porteble rrodech
RECEPTACLES
................... ........ C^UTiON
Receptacles may be marked wtdi rating value greater
than generator output capacity.
NEVER, latt^mpttpippwara device irequiringi more
amperage ithanigeneratPPiP :receptac)eican supp y.; y y y
DO NOT overload the ;^neraton See "Don’t Overload
Generator”,
Use each recepude to operate 120 Volt AC, single-phase,
60 Hz electrical loads requiring up to 2,400 mtts (2.4 kW)
at 20 Amps of current. Use cord sets that are rated for
125 Vo t AC loads at 20 Amps (or greater),
120 Volt AC, 30 Amp Locking
Receptacle______________________
Use a NEMA L5-30 plug with this lecepude. Connect a
3-^ire cord set rated for 125 Vo t AC loads at 30 Amps to
the plug (Figure 10),
120 Volt AC, 20 Amp, Duplex
Receptacle______________________
Each receptac e (Figure 9) is protected against overload by
a 20 Amp push-to-reset circuit breaker.
Figure
9—
l20VoltAC.2€
Amp,
Duplex Receptacle
