Section 6 — Exploded Views and Parts Lists
^PARTS
LISTS
Cenerac Q-70G Recreational Vehicle Generator
Carburetor - Drawing No. 93753-F
ITEM
PART NO.
QTY.
DESCRIPTION
1
73112B
1
CARBURETOR ASSEMBLY
2
74962c
1
SPRING, GOVERNOR
74962g
1
SPRING, GOVERNOR q-70g
3
70155
1
LEVER, GOVERNOR
4
70108
1
ROD, GOVERNOR TO CARBURETOR
5
56893
5
SCREW (CRIMPTITE) - #10-24 X 1/2”
6
74961
1
BRACKET, GOVERNOR ADJUSTER
7
47227
1
SCREW, GOVERNOR ADJUSTER
8
37398
1
NUT, HEX LOCK (NYLON)
9
73131
1
BRACKET, AIR CLEANER SUPPORT
10
66476
2
SCREW, HEX - M6-1.0 X 12MM
11
70575
2
SCREW, HEX - M6-1.0 X 25MM
12
70125
1
SPRING, ANTI-LASH
13
73374
1
BRACKET, CHOKE SUPPORT
14
74947
1
ROD, CHOKE CONTROL
15
89473
1
BI-METAL ASSEMBLY, CHOKE
16
91306
1
SOLENOID, CHOKE
17
77091
1
HAIR PIN, COTTER
18
31879
4
FLAT WASHER - #4
19
22159
4
LOCK WASHER - #4
20
89870
1
SOLENOID FUEL SHUT-OFF (Q70G ONLY)
21
72536
4
SCREW, PAN HD, MACH. - #4-40 X 1/4”
22
87770
1
LINE, FUEL - 5/16” I.D.
23
74946
1
LINK, CHOKE
25
30340
1
HOSE - FUEL, 4.5” LG.
26
C2338B
1
DECAL, AIR CLEANER PRIMEPACT 66G
C2338
1
DECAL, AIR CLEANER - PRIMEPACT 55G
91352C
1
DECAL, AIR CLEANER - Q-70G
27
75252
1
KIT, CARBURETOR OVERHAUL - NOT SHOWN
28
A7782A
1
FLYWHEEL ASSEMBLY
29
40173
2
CLAMP, HOSE (SCREW TYPE)
30
66829
2
RIVET - 1/8” DIAMETER X 1/8” LONG
31
75944
1
BRACKET, GOVERNOR SPRING
32
70594
2
CAPSCREW, HEX HD. - M6-1.0 X 93 LG. W/WASHER
33
77075
1
COVER, CHOKE COIL
Generac* Power Systems, Inc. 27
