Section 6 — Exploded Views and Parts Lists
jpms
LISTS
Generac Q-70G Recreational Vehicle Generator
Engine Sheet Metal - Drawing No. 89403-K
ITEM
PART NO.
QTY.
DESCRIPTION
1
1
SEE ENGINE EXPLODED VIEW of ENGINE
2
99258
1
KEY-WOODRUFF 6 x 22MM
3
67198N
1
BEVELED WASHER
4
67890
1
HEX NUT
5
87865
1
PLUG, FLYWHEEL ACCESS
6
A4456
1
3/8" SPECIAL LOCK WASHER
7
86313
1
HOUSING, ENGINE TOP
8
56893
23
SCREW (CRIMPTITE) NO. 10-24 x 1/2"
10
87750
1
SCROLL, FLYWHEEL
11
74916
1
COVER, BASE CYL. #2
12
74908
9
SCREW (TAPTITE) M5 x 10MM
13
73190
1
WRAPPER CYL. #2
14
78858
1
COVER, VALLEY
15
78859
1
WRAPPER, CYL. #1
16
74902
2
WRAPPER, BARREL
17
66476
4
HHCS/LW-M6
x
1.0
X
12MM
19
73191
1
COVER, BASE CYL. #1
20
42907
2
CAPSCREW, HEX HD.-M8 x 1.25 x 16MM
21
22129
2
LOCK WASHER-M8
22
75246
4
SCREW (TAPTITE) 3/8"-16 x 1-1/4"
23
10^-74260
1
WIRE ASSEMBLY-NO, 16
24
74900
1
STARTER COVER
25
73186
1
WRAPPER, CRANKCASE
26
81108
1
BUSHING, SNAP
27
22717B
1
GROMMET -RUBBER
28
22717A
3
GROMMET -RUBBER
29
67866A
1
0-RING
30
77001A
1
PLUG, OIL FILL
31
73132
2
BOOT, SPARK PLUG
33
87858A
1
GROUND WIRE ASEMBLY-CYL. #1
34
29289
2FT.
FOAM TAPE
35
87858B
1
GROUND WIRE ASSEMBLY-CYL. #2
36
50277
1
OIL DRAIN DECAL
