Section 6 — Exploded Views and Parts Lists
^PARTS
LISTS
Cenerac Q-70G Recreational Vehicle Generator
Engine - Drawing No. 79216-E
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 69331 1 CYLINDER ASSEMBLY 43 75253 4 WASHER VALVE COVER SEAL
2 69333 1 SLEEVE BEARING 44 67885 4 M6 NYLON NUT
3 67805 1 OIL SEAL 45 75254 4 VALVE ADJUST SCREW
4 79234 1 NO. 1 CYLINDER HEAD ASSEMBLY 46 70535 1 OIL SCREEN
5 79235 1 NO. 2 CYLINDER HEAD ASSEMBLY 47 C2881 1 STARTER MOTOR (NOT SHOWN)
6 70169 4 SEALING WASHER 51 72536 4 IGNITION ARMATURE SCREW
7 69332 2 CYLINDER HEAD GASKET 52 72347 2 SPARK PLUG
8 104 85110 1 BREATHER ASSEMBLY 53 75258 1 ENGINE GASKET KIT
9 72315 1 BREATHER GASKET 57 66480 1 AIR CLEANER GASKET
10 89967 1 BREATHER SCREW 59 72361 1 GOVERNOR SHAFT BUSHING
11 70596 1 BREATHER TUBE 60 72362 1 GOVERNOR SHAFT BUSHING
12 69336 1 OIL SUMP GASKET 61 70199 1 BREATHER BAFFLE
13 69325 8 CYLINDER HEAD BOLT 62 72366 1 COTTER PIN
14 67888 2 3/8” NPT OIL DRAIN PLUG 64 72365 1 GOVERNOR SHAFT WASHER
15 72334 1 CRANKSHAFT ASSEMBLY 65 68555 2 CRANKCASE DOWEL
16 75247 1 OIL SUMP ASSEMBLY 66 67806 4 CYLINDER HEAD DOWEL
17 67924 1 OIL SEAL ASSEMBLY 73 68572 2 OIL PUMP SCREW
18 67878 9 OIL SUMP BOLT 74 75272 2 SPARK PLUG TERMINAL
19 75248 2 STANDARD PISTON ASSEMBLY 75 70122 4 VALVE STEM SEAL
20 75249 2 STANDARD PISTON RING SET 76 67910 2 INTAKE VALVE SEAT
21 69327 4 PISTON LOCKING RING 78 67813 4 VALVE GUIDE
22 75250 2 STANDARD PISTON RING 81 70592 1 AIR CLEANER BASE
23 75251 2 CONNECTING ROD ASSEMBLY 82 73123 1 AIR FILTER (NOT SHOWN)
24 72346 4 CONNECTING ROD BOLT 83 70593 1 AIR CLEANER COVER
25 69316 2 EXHAUST VALVE 84 C3633 1 AIR CLEANER COVER SCREW
26 69317 2 INTAKE VALVE 85 67156 2 AIR CLEANER BASE SCREW
27 67816 4 VALVE SPRING 86 69341 1 FOAM PRE-CLEANER
28 69320 4 VALVE SPRING RETAINER 88 70597 1 AIR INLET TUBE
29 70513 4 VALVE KEEPER 89 72305 1 BREATHER DEFLECTOR
30 70584 4 VALVE TAPPET 90 67920 2 VALVE COVER GASKET
31 70530 1 CAMSHAFT ASSEMBLY 91 69328 2 VALVE COVER
32 72358 1 INTAKE MANIFOLD 92 70547 1 OIL PUMP ASSEMBLY
33 69379 2 CARBURETOR MOUNTING GASKET 93 70536 1 GOVERNOR SLIDER
34 67895 2 INTAKE MANIFOLD GASKET 94 70577 4 PUSH ROD
35 70594 2 CARBURETOR MOUNTING BOLT 95 70599 4 ROCKER ARM
36 67158 4 INTAKE MANIFOLD MOUNTING BOLT 97 70566 4 ROCKER ARM SUPPORT
37 68574 1 1/8” NPT PLUG PIPE 98 75271 1 VALVE OVERHAUL KIT
38 68554A 1 GOVERNOR SHAFT SEAL 99 67897 2 EXHAUST GASKET (NOT SHOWN)
39 68573 1 OIL PUMP O-RING 100 91481 1 GASKET AND CAP ASSEMBLY
40 70506 1 OIL GALLEY O-RING 101 91480 1 ROCKER ARM AND COVER
41 70554 1 CARBURETOR SPACER 102 Dll 98 1 GOVERNOR CRANK
42 70568 4 ROCKER ARM STUD
Generac* Power Systems, Inc. 53
