MTD 249-623-003 - Manual (Page 18)

424/LCD/22 (Model 623)
PARTS LIST FOR MODEL 623 LOG SPLITTER
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 712-0299 Hex Castle Nut 3/4-16 Thd. 43 712-0375 Hex L-Nut 3/8-16 Thd.
2 714-0162 Cotter pin 5/32" Dia. 44 712-0798 Hex Nut 3/8-16 Thd.
3 734-0873 Hub Cap 45 713-0338 Chain—Tow Hitch
4 734-1016 Wheel Ass’y- Comp. 46 715-0249 Spring Roll Pin 5/32" Dia.
734-0872 Tire Only 47 727-0311 Hitch Coupler
734-1017 Rim Only 49 736-0116 FI-Wash. .635" I.D. x .93" O.D.
734-0255 Air Valve 50 736-0169 L-Wash. 3/8" I.D.*
5 736-0351 FI-Wash. .76" I.D. x 1.5" O.D. 51 736-0185 FI-Wash. .406" I.D. x .75" O.D.
6 741-0107 Roller Bearing 52 750-0507 Spacer .27" Lg.
7 736-0921 L-Wash. 1/2" I.D.* 53 781-0358 N Jack Stand Ass’y.
8 737-0192 90° Solid Male Adaptor 54 781-0368 Tongue Tube
9 737-0238 Pipe Nipple 1/2 NPT 55 781-0370 N Locking Rod
10 750-0442 Spacer 1.56" Lg. 56 781-0388 N Beam Support Ass’y.
11 781-0386 N Stripper Ass’y- 57 723-0405 Filter Element
12 710-3104 N Hex Bolt 1/2-13 X 21/4" Lg. 58 723-0406 Filter Head
(Grade 5) 59 726-0146 Adj. Hose Clamp
13 712-3034 N Hex Nut 1/2-13 Thd. (Grade 5) 60 727-0309 Return Hose 3/4" I.D. x 30" Lg.
14 710-1010 Hex Bolt 1/2-20 X 3" Lg. 62 781-0339 N Vertical Beam Ass’y.
(Grade 8) 64 710-0520 Hex Bolt 3/8-16 X 1.5" Lg. (Gr! 5)
15 710-1018 Hex Bolt 1/2-20 X 2.75" Lg. 66 714-0470 Cotter Pin 1/8" Dia.
(Grade 8) 68 738-0736 Hinge Pin
16 710-1032 N Hex Bolt 3/8-24 x 1.5" Lg. 70 781-0373 N Beam Hinge
17 712-0239 Hex L-Nut 1/2-20 Thd. 71 781-0375 N Beam Hinge Back Plate
18 712-0333 Hex Nut 1/2-20 Thd. 72 781-0377 N Beam Hinge Spacer
19 712-3001 Hex Jam Nut 3/8-24 Thd. 73 710-0117 Hex Bolt 5/16-24 X 1" Lg.
(Grade 5) 74 710-0237 Hex Bolt 5/16-24 x .62" Lg.
20 736-0192 FI-Wash. .53" I.D. x .94" O.D. 75 710-0363 Hex Bolt 5/16-24 x 4" Lg.
21 732-0583 Comp. Spring 4" Lg. 76 712-0123 Hex Nut 5/16-24 Thd.
22 750-0750 N Spacer 1 / 2 " I.D. x .86" Lg. 77 714-0122 Sq.-Key 3/16" x .75"
23 781-0393 N Wedge Ass’y. 78 717-0891 Flexible Coupling
24 781-0345 N Pusher Back Plate 79 717-0936 N Two Volume Pump
25 781-0350 N Fixed Side Gib 80 719-0281 Coupling Shield
26 781-0351 N Adjustable Gib 81 726-0132 Hose Clamp 5/8"
27 781-0352 N Adjustable Gib Shim 82 727-0427 N Suction Hose 1" I.D.
28 781-0356 N Floating Gib Plate i lT83 727'0432-0 S33N High Pressure Hydraulic Hose45®*’
29 714-0203 N External Cotter Pin 84 736-0119 L-Wash. 5/16" I.D.*
30 715-0206 N Cylinder Mounting Pin 85 781-0097 Rear Coupling Support Brkt.
31 717-0893 N Hydraulic Cylinder 86 781-0098 Front Coupling Support Brkt.
32 717-0942 N Control Valve 87 710-0157 Hex Bolt 5/16-24 x .75" Lg.
33 727-0307 Metal Pressure Tube 88 710-0409 Hex Bolt 5/16-24 x 1.75" Lg.
T34 727-0440 N Pressure Tube 89
—
Engine
r 35 737-6'i?1-£ Zi>5 90° Solid Male Adaptor5(/ c^aa /90 736-0159 FI-Wash. .344" I.D. x .875" O.D.
37 737-0235 3 / 4 " Hose Barb. 91 737-0236 L-Vent Pipe Plug
39 710-0521 Hex Bolt 3/8-16 X 3" Lg. 92 735-0639 Spark Plug Boot
(Grade 8) 93 781-0271 Fender
40 710-0615A N Hex Bolt 3/8-16 X 5" Lg. 94 781-0312 Strainer Ass’y.
41 710-3130 Hex Bolt 3/8-16 X 3.25" Lg. 95 781-0376 N Tank Ass’y.
(Grade 8) 96 720-0231 N Ball Knob
42 711-0820 N Quick Release Pin 97 747-0709 N Control Handle
*For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
NOTE: The engine is not under warranty by
the log splitter manufacturer...If repairs or
service is needed on the engine, please
contact your nearest author­
ized engine service outlet.
Check the “Yellow Pages” of
your telephone book under
“Engines—Gasoline.”
Find If Fast
In The
Yellow Pages
19
