MTD 24650-9 - Manual (Page 13)

Model 650
PARTS LIST FOR MODEL 650 SHREDDER
'>ef.
.tio.
Part
No.
Color
Code
Description
New
Part
Ref.
No.
Part
No.
Color
'Code
Description
New
Part
1 11476 Door Chip It 31 714-0144 Cotter Pin 1/8" Dia. x 1.00"
2 710-0465 Hex Bolt 1/2-20 x 4.50" Lg.* Lg.* (Special)
3 711-0580 Clevis Pin 32 736-0192 Fl.-Wash. .531" I.D. x 937
4 711-0579 Flail Spacer 7/32" Lg. O.D. X .09
5 11455 Cutting Finger 33 11459A Flail N
6 736-0921 L-Wash. 1/2" I.D.* 34 711-0564 Flail Spacer 23/32" Lg.
7 726-0111 Palnut 3/16" Dia. 35 711-0578 Clevis Pin .50" Dia. x 3.0" Lg.
8 712-0922 Hex Jam Nut 1/2-20 Thd.* 36 736-0247 Fl.-Wash. .406" I.D. x 1.25"
9 714-0507 Cotter Pin 3/32" Dia. x 3/4" O.D. Hdn.x
Lg- 37 736-0217 L.-Wash. 3/m: I.D. H.D.
10 16568 Chute Deflector 38 710-0151 Hex Bolt 3/8-\24 x 2.0" Lg. H.T.
11 712-0107 L.-Nut 1/4-20 Thd. 39 14575-638 Flail Housing Ass'y-Comp.
12 710-0289 Hex Bolt 1/4-20 x .50" Lg.* 40 732-0546 Torsion Spring .062 Dia. x 1.06
13 714-0114 Sq. Key 1/4" x 2.00" Lg. Lg.
14 13430 Impeller Assembly 41 11477 Chip-lt Guide Ass'y.
15 710-0157 Hex Bolt 5/16-24 x 3/4" Lg. 42 11478 Hinge Pin
16 736-0119 L.-Wash. 5/16" I.D.* 43 747-0531 Release Bar
17 14573 Hopper to Engine Mtg. Plate 44 712-0109 Wing Nut Elastic 1/4-20 Thd.
18 Engine 45 13431 Blade
19 11464A Engine Mounting Plate N 46 11460-638 Upper Leaf Ramp Section
20 712-0123 Hex Nut 5/16-24 Thd.* 47 16524-638 Lower Leaf Ramp Section
21 736-0119 L.-Wash. 5/16" I.D.* 48 736-0264 Fl.-Wash. 5/16" I.D.
22 738-0521 Shaft 49 11481A-638 Hopper Assembly N
23 736-0170 Special L-Wash. 5/16" I.D. 50 710-0601 Hex Wash. Hd. Self-Tap Scr.
^24 726-0221 Push Cap 5/16-18 X .75" Lg.
25 711-0494 Spacer 52 11454 Back-Up Plate
26 734-1056 Wheel Ass'y.-Comp. (White) 53 16522 Inlet Guide Assembly
734-1173 Wheel Ass'y-Comp. (Silver) 55 11480 Stop Washer
28 710-0624 Hex Bolt 5/16-24 x 1.50" Lg.* 56 710-0542 Hex Bolt 5/16-18 X 8.38" Lg.
29 712-0429 Elastic Lock Nut 5/16-18 Thd. 57 735-0639 Spark Plug Boot (Optional)
30 710-0237 Hex Bolt 5/16-24 x .62" Lg.* — 764-0199 Bag (Not Shown)
— 723-0400 Safety Glasses (Not Shown)
*For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order part
number and size as shown on parts list.
638-Red
621 —Brilliant Fire Mist
483—Charcoal Gray
yyhen ordering parts if color or finish is important, use color code shown at left,
[i.e. (part no.) —638 for Red Finish]
The engine is not under warranty by the shredder manufacturer. If repairs or service is needed on the engine,
please contact your nearest authorized engine service outlet. Check the "Yellow Pages" of your telephone
book under "Engines —Gasoline."
Find If Fast
In The
Yellow Pages
NOTE
Specifications Subject to change without
notice or obligation.
13
