C. POWER UNIT ^ DESCRIPTION
KEY
NO.
PART
NO.
QTY.
REQ.
DESCRIPTION
KEY
NO.
PART
NO.
QTY.
REQ.
DESCRIPTION
1
10729
1
Fuel CapAssembiy (incl. 0-Ring)
65
27100
1
Cover-Carburetor Case
2
25377
1
Bracket-Fuel Tank
66
15673
1
Spacer
3
92243
1
Screw-Bracket Handle
67
27189
1
Carburetor Case Ass’y.
(#1/4-10x1-1/8")
68
19108
1
-j- Gasket-Carburetor Case Crankcase
4
10887
1
Fuel T ank Ass’y. (inci. #1,16 & 37)
69
24438
1
Reed Valve
5
15509
2
Screw-Fuel Tank Fan Hsg. {#10x1")
70
23367
1
Washer-Reed Valve
6
15158
2
Washer-Fuel Tank Fan Hsg.
71
15241
1
Screw-Reed Valve (#6-19x5/16")
7
15590
4
Screw
72
32092
1
Bearing-Wrist Pin
8
24371
1
Air Filter
73
69240
1
Piston Kit (Incl. #56. 57 & Pin)
9
26735
1
Handle, Starter
74
12070
1
Cylinder
10
10891
1
Fan Housing Ass'y-
76
24903
2
Spring-Muffler Attachment
11
15594
2
Screw-Fan Housing-Bottom
77
30077
1
Spark Plug (CJ-14)
#10-24x1-1/8 Bind. Hd.
78
69243
1
Muffler Ass’y.
12
27190
1
Throttle Wire
81
69196
1
Kit-Washer-Clutch
13
69231
1
Rope Kit
82
69194
1
Kit-Ass’y{lncl. Clutch Washer)
14
15723
1
Screw
83
25342
1
Trigger-Throttle
16
10897
1
Fuel Pick-Up Ass’y.
84
15382
1
Washer-Throttle
18
42067
1
Starter-Recoil Spring
85
15407
1
Screw-Throttle (#8-16x3/8")
19
26048
1
Starter-Pulley
86
15740
1
Screw
20
26679
1
Button-Kill Switch
87
10797
1
Drum and Coupling Ass’y
21
26559
1
Spring-Kill Switch
88
15274
4
Washer-Fiat-Shroud
22
15382
1
Washer-Kill Switch
89
25704
1
Handle
23
15407
1
Screw-Kill Switch (#8x3/8")
90
15163
4
Screw-Shroud #10-24x7/8"
24
30054
1
Crankcase Sealant-3
02
. tube
91
26560
1
Clamp-Shroud
(Optional)
93
15610
1
Nut #1/4-20-Clamp
25
15123
1
Washer-Starter Pulley
94
26547
1
Shroud
26
15479
1
Screw-Starter Pulley (#10-3/4"
96
15609
1
Bolt, Clamp (#1/4-20x9/16")
HexHd.)
97
35017
1
Screw-Pump Cover
27
626605
1
Nut-Ftywheel
98
35191
1
Pump Cover Ass’y. (incl. #124)
28
42059
2
Spring-Starter Dog
99
35164
. 1
*+Gasket-Pump
29
15127
1
Washer-Flywheel
100
35166
1
♦^-Diaphragm-Pump
30
39114
1
Flywheel-Ass'y. (Incl. #28)
101
35178
1
+
Screen-Inlet
31
15369
4
Screw-Crankcase
102
69219
1
Kit-Engine Gasket
32
27101
1
Knob-Choke
(tlndicates Contents)
33
26961
1
Fitting-Fuel Line
103
35015
2
■+
Screw-Throttle Shaft
34
21073
1
Fuel Line-Carburetor
104
35007
1
Clip-Throttle Shaft
35
19059
2
f Seal-Crankshaft
105
35106
1
-t- Valve-Inlet Needle
36
15741
1
Washer
106
35139
1
+ Spring-Metering Lever
37
69247
1
Line- Kit
107
35031
1
+ Lever-Metering
38
15128
2
Screw-Ignition Module (#8-32x3/4"
108
35028
1
■+
Pin-Metering
Sems)
109
35016
1
Screw-Metering Lever Pin
39
69181
1
Ignition Module Kit
110
35014
1
*-M0iaphragm Assembly-Metering
40
24435
1
Grommet-Plug Wire
111
35149
1
-i- Cover-Metering Diaphragm
41
39082
1
Lead Wire-High Tension
112
35153
4
Screw Assembly-Metering Cover
42
19105
1
f Seal-CarburetorCase
113
35151
1
"-Kaasket-Metering-Diaphragm
45
10757
1
Cran kcase Ass ’ y. (1 ncl. #35,52 and
114
35137
1
■+
Screw-Circuit Plate
Qty.4of31)
115
35042
1
Plate Circuit
46
15630
1
Screw-Carburetor
116
35147
1
"-i-Gaskei-Circuit Plate
47
15254
1
Wave Washer
117
35036
1
Spring-Hi Speed Needle
48
26772
1
Shutter-Choke
118
35142
1
Needie-Hi Speed
49
26797
1
Piate-Guide
119
35141
1
Needle-Idle
50
35183
1
Carbureior-WA-149
120
35023
1
Spring-Idle Needle
51
19115
1
f Gasket-Carburetor
121
35132
1
Shaft Assembly-Throttle
52
32029
2
Bearing-Crankshaft
122
35138
1
Spring-Throttle Return
53
15351
2
Thrust Washer-Crankshaft
123
35133
1
Valve-Throttle
54
15126
1
Key-Flywheel
124
35156
1
Screw-Idle Adjustment
55
10844
1
Crankshaft
&
Rod Assembly()nci. # 72)
125
35186
1
Kit-Carb. Kwik Repair
56
15162
2
Retainer-Wrist Pin
(+ Indicates contents)
57
27369
1
Piston Ring
126
35185
1
Kit-Carb. Gasket/Diaphragm
58
19111
1
t Gasket-Cylinder
{* indicates contents)
59
15239
2
Screw-Cylinder (#1/4-20x3/4"
Decals
Socket Hd.)
A
27312
1
Decal-Starting Instructions
60
3933
1
Connector-Spark Plug
e
27457
1
Decat-Choke/OFF
61
3934
1
Boot-Spark Plug
Not Shown
62
39103
1
High Tension Lead Ass’y.
—
26612
1
Decal-Shroud (Right)-Not Shown
(Inci, #41,60, &61)
—
26613
1
Decal-Shroud (Left)-Not Shown
63
15674
1
Screw-Carburetor
64
15235
4
Screw-Carburetor Cover (#8-18x9/16")
65
27100
1
Cover-Carburetor Cover (#8-18x9/16")
____________ ______ ____________________
* Indicates Carb Gasket/Diapfiragm Kit Contents
+ Indicates Contents in Carb Kwik Repair Kit
t Indicates Engine Gasket Kit Contents
