Models 315B and 315D
tEF.
'JO.
PART
NO.
DESCRIPTION
QTY.
1
629-0241
HARNESS-CHIPPER VAC
1
2
681-0059
HOUSING ASSY—INNER
1
3
681-0060
HOUSING ASSY—OUTER
1
4
710-0382
SCREW-HEX
2
5
710-0604
SCREW-HEX SELF TAP
10
6
710-0607
SCREW-HEX SELF TAP
8
7
710-0772
SCREW-HEX
3
8
710-1268
SCREW- HEX SELF TAP
2
9
710-3008
SCREW-HEX
2
10
712-0384
NUT-HEX LOCK
2
11
712-0421
KNOB
3
I2
712-3004A
NUT-HEX LOCK
4
I3
712-3010
NUT-HEX (GR 5)
3
I4
719-0326
SCREEN
1
I5
723-0438
SEAL-RUBBER
2
I6
725-1700
COVER-SWITCH
1
I7
725-3166
SWITCH
1
I8
726-0272
CLAMP
1
I9
731-1613
COVER SWITCH
1
?0
736-0119
WASHER-LOCK
3
736-0242
WASHER-BELL
3
12
781-0598
BLADE-FLAIL HOUSING
1
13
781-0599
BLADE-FLAIL HOUSING
1
14
781-0627
COVER-CHIPPER
1
REF.
NO.
PART
NO.
DESCRIPTION
QTY.
1
681-0068
CHUTE ASSEMBLY
1
2
710-0258
SCREW HEX
5
3
712-3027
NUT-LOCK
5
4
731-1609
CHUTE -CHIPPER UPPER
1
731-1574
(315B)
CHUTE-CHIPPER UPPER
1
5
736-0173
(315D)
FL-WASH. .28" I.D. x .73" O.D.
5
6
781-0625
BRACKET SUPPORT
1
7
735-0249
FLAP
1
8
781-0633
STRIP-FLAP
1
9
728-0175
RIVET
3
—
731-1617
TAMPER PLUG
(Not Shown—Optional)
1
7A — Page 3
