Models 315B and 315D
REF.
NO.
PART
NO.
DESCRIPTION
QTY.
REF.
NO.
PART
NO.
DESCRIPTION
QTY.
1
1539-019
PUSHNUT
4
15
720-0232
KNOB-SHIFT
1
2
647-0019
CONTROL ASSY
1
16
725-0157
CABLE TIE
1
3
649-0008
HANDLE ASSY-UPPER
1
17
735-0126
WASHER-RUBBER
1
4
649-0012
HANDLE ASSY-LOWER
1
18
736-0264
WASHER-FLAT
1
5
681-0076
BRACKET ASSY-SHIFT
1
19
736-0300
WASHER-FLAT
1
6
710-0116
SCREW-HEX
4
20
736-0413
WASHER-SPRING
2
7
710-0380
SCREW-HEX
2
21
736-0451
WASHER-SADDLE
6
8
710-0896
SCREW-HEX
2
22
738-0560
SCREW-SHOULDER
1
9
710-3008
SCREW-HEX
5
23
738-0561
NUT-SHOULDER
1
10
711-0677
FERRULE
1
24
741-0402
BEARING-FLANGE PLASTIC
2
11
711-0737
PIN-STUD
4
25
746-0921
CABLE-CLUTCH
1
12
712-0116
NUT-HEX LOCK
1
26
747-0626
ROD-SHIFT
1
13
712-3004A
NUT-HEX LOCK
11
27
781-0626
COVER-SHIFT
1
14
714-0104
PIN-COTTER
2
28
784-0297A
HANDLE-SHIFT
- ^
COLOR CODES: 788-0637—BLACK 788-0662- OYSTER GRAY
7A — Page 2
