Parts List
MODELS 12089, 12090, 12204
W HEELS/TINES/PTO DRIVE LEVER & YOKE ASSEMBLY
REF
\lo.
PART
No.
DESCRIPTION
QTY.
REF
No.
PART
No.
DESCRIPTION
QT\
1
2574
Lever-Wheels/TInes/PTO Drive
10
1900860001
Link-yoke pivot, left & right,
(Incl. knob w/decal)......................
1
6-7/8" long................................... . 2
2
1908156
Spring-clutch pawl............................
1
11
1100046
Bolt-hex hd., 3/8-16x1"................... . 6
3
1100799
Bolt-hex hd., 5/16-18x1-1/2".....,
3
12
1100243
Lockwasher-spring lock, 3/8"......
. 6
4
2447
Bushing-3/8".....................................
3
13
1107383
Washer-flat, 3/8", S.A.E................... . 6
5
1177548
Lockwasher-external tooth, 5/16"
3
15
1186231
Nut-hex, 3/8"-16.............................. . 2
6
1186230
Nut-hex, 5/16"-18.............................
3
16
1113-1
Bushing-spacer, 19/64" (.300")...
. 6
7
1916265001
Roller Assembly.................................
1
17
—-
Knob-not avail, separately. See
8
1900468001
Yoke-left side....................................
1
Ref No. 1.......................................
9
1900469001
Yoke-right side............. ....................
1
