Troy-Bilt 12090 - Manual (Page 61)

MODELS 12090, 12204
Parts List
REF
No.
PART
No. DESCRIPTION QTY.
REF
No.
PART
No. DESCRIPTION QTY.
1 96515 Cabie-battery, positive and negative 23 9265 Tie-plastic, wire retaining................ 1
terminals...................................... 2 24 9009 Vent Tube-5/16" diameter .............. 1
2 97020 Boot-terminal insulating ................. 3 25 1475 Shield-vent tube, 1/2" diameter... 1
3 9552 Screw-se If-th read i ng, 26 9224 Clamp-vent tube shield.... ............... 1
1/4-20x1/2".................................. 3 27 9202 Tie-plastic......................................... 2
4 1186309 Bolt-hex hd., 1/4-20 x 5/8".............. 2 28 1908118 Wire Harness & Connecting
5 1901894 Wire-recharge (red) for Briggs Terminal Assy-for Briggs & Stratton
and Stratton engine (incl. engines(available as
terminal and eyelet)................... . 1 complete assembly only). Incl.
6 1904564 Battery Hold-down Clamp-with wire assy., w/connector to large
attached Key Switch Plate (incl. solenoid stud (red wire): wire
Ref. No. 7)................................... 1 assy, w/connector to small
7 1904548 Decal-ignition switch instruc.......... . 1 solenoid stud (red wire): wire
8 1908112 Key Switch-includes two assy, w/connector to solenoid
ignition keys (Ref No. 9), one grounding screw (red wire): wire
lockwasher, and one mounting assy w/connector to engine ground
nut (lock-washer and nut not shut-off (green wire); plastic
available separately).................... 1 protector tube; wire harness:
9 96520 Key-ignition, one pair....................... 1 connector: wire terminal... ......... 1
10 9566 Bolt-carriage, 1/4-20 x 1-1/4".......... 2 29 1908117 Wire Harness-for Kohler engine.
11 1100241 Lockwasher-spring lock, 1/4"......... . 2 Incl. two receptacles; three red
12 1186229 Nut-hex, 1/4"-20............................. 4 wires (solenoid activate, battery
13 9092B Battery-12 volt, 30 amps., side- recharge, and starter switch);
vented, (incl. Ref No. 24,4,12) 1 two green (ground)(shutoff)
14 96514 Solenoid-starter, includes nuts and wires; plastic harness tube.......... 1
washers for cables and wires... 1 30 1186389 Locknut-hex, 1/4"-20....................... 2
15 1100242 Lockwasher-5/16"........................... 2 32 1901202 Cable-ground, solenoid to engine
16 1186211 Nut-hex, 5/16"-24........................... 2 block........... .................. . 1
17 1187559 Lockwasher-external tooth, #10.. 1 33 1186331 Bolt-flange lock, 5/16-18 x 1".......... 1
18 1186208 Nut-hex, #10-32........... ................... 1 34 1186391 Nut-flange lock, 5/16"-18................ 1
19 96510 Cable-solenoid to starter motor.. 1 35 1917269 Ground Wire Assembly................ 1
20 2571 Battery Bracket................................ 1
21 1186349 Bolt-flanged hex hd..
3/8-16x1-1/2".......... ................... 2
61
