MTD 112-162A - Manual (Page 11)

Models 152 and 162
PARTS LIST FOR MODELS 152 AND 162 ROTARY MOWERS
REF.
NO.
PART NO.
(Model 152)
COLOR
CODE
PART NO.
(Model 162)
COLOR
CODE
DESCRIPTION
NEW
PART
3 731-0275 731-0275 Shroud
4 710-0289 710-a289 Hex Bolt V4-20 X .50" Lg.
5
—
— Engine
6 710-0654 710-0654 Hex Wash. Hd. Self-Tap Scr. 3/8-16 x .88" Lg.
7 12935 12935 Handle Mtg. Brkt. Ass’y.
8 12428 -462 12421 -462 Deck Assembly—Complete
9 10938 10938 Height Adj. Ass’y-—Complete—L.H.
10 736-0119 736-0119 L-Wash. 5/16 Scr.*
11 712-0123 712-0123 Hex Nut 5/16-24 Thd.*
12 714-0365 714-0365 #6 Hi-Pro Key 5/32 x 5/8" Dia.
13 10769 10769 Blade Adapter Kit
14 742-0123 742-0125 Blade
15 736-0217 736-0217 L-Wash. 3/8" Scr.—H.D.
16 710-0459 710-0459 Hex Bolt 3/8-24 x 1.50" Lg. —H.T.
18 14082 14082 Spring Lever Ass’y. with Knob
19 736-0219 736-0219 Belleville Washer
20 712-0116 712-0116 Elastic L-Nut 3/8-24 Thd.
21 710-0209 710-0209 Sems Hex Bolt 3/8-16 x .62" Lg.
22 10937 10937 Pivot Bar
23 10935 10935 Index Plate Ass’y. —L.H.
10934 10934 Index Plate Ass’y. — R.H.
24 10941 10941 Height Adj. Ass’y.—Complete R.H.
25 710-0117 710-0117 Hex Bolt 5/16-24 x 1.00" Lg.—H.T.
26 736-0105 736-0105 Belleville Washer
27 734-0876 734-0661 Wheel Ass’y.—Complete
28 738-0102 738-0102 Axle Bolt
29 10769 10769 Blade Adapter Kit
30 11679 -462 11679 -462 Chute Deflector Ass’y.
31 732-0253 732-0253 Torsion Spring
32 710-0603 712-0603 Hex Wash. Hd. Self-Tap Scr. 5/16-24 x .50" Lg.
34 711-0555 711-0555 Pivot Pin
35 710-0567 710-0567 Hex Bolt V4-28 x .62" Lg.
36 11130 -462 11130 -462 Adapter Plate
37 726-0106 726-0106 Push-On Flange Palnut
38 714-0104 714-0104 Hairpin Cotter
39 12936 12936 Handle Mtg. Brkt. Ass’y.
40 12251 -462 14084 -462 Rear Protective Shield Ass’y. —Comp.
42 726-0188 726-0188 Cable Tie
43 746-0229 746-0229 Conduit and Wire
45 710-0227 710-0227 Hex Wash. Hd. AB-Tap. Scr. #8 x .38" Lg.
47 746-0202 746-0202 Throttle Control Comp.
48 712-0107 712-0107 Hex Cent. L-Nut V4-20 Thd.
49 710-0405 710-0405 Curved Hd. Bolt 5/16-18 x 1.75" Lg.
50 09966 09966 Hand Knob
51 710-0606 710-0606 Hex Bolt V4-20 X 1.50" Lg.*
52 731-0344 731-0344 Plastic Cover
53 749-0384 749-0384 Upper Handle (Chrome)
749-0383 749-0383 Upper Handle (Painted)
54 718-0145 718-0145 Grip
55 749-0449 749-0449 Lower Handle (Chrome)
749-0448 749-0448 Lower Handle (Painted)
63 741-0262 741-0262 Fortiflex Bearing (2 per wheel)
64 726-0134 726-0134 Speed Nut #8-32—Twin Type
65 712-0107 712-0107 Hex Cent. L-Nut V4-20 Thd.
*For faster service obtain standard nuts, bolts and washers
locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list,
(462—Red Flake)
When ordering parts, if color or finish is important use the ap­
propriate color code shown above, (e.g. Red Flake
Finish—12609(462).)
11
NOTE: The engine is not under warranty by
the mower manufacturer ... If repairs or
service is needed on the engine, please
contact your nearest author­
ized engine service outlet.
Check the “Yellow Pages” of
your telephone book under
“Engines—Gasoline.”
