PARTS LIST FOR FIGURE 9 MODEL 244-650A
REF.
NO. PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 1 1476—403 Door—Upper Guide Extension
2 710-465 Hex Scr. '/2-20 X 4.50" Lg.*
3 711-580 Clevis Pin
4 711-579 Flail Spacer 7/32" Lg.
5 11455—463 Cuffing Finger
6 736-921 Lockwasher '/ 2 " Scr.*
7 726-111 Palnut 3/ 16" Dia.
8 712-922 Hex Jam Nuf '/2-20 Thd.*
9 714-507 Cotter Pin 3/32" Dia. x %" Lg.*
10 11465—463 Chute Deflector
11 712-107 L-Nut '/ 4-20 Thd.
12 710-289 Hex Scr. '/ 4-20 X .50" Lg.*
13 714-114 Sq. Key ’/ 4 " X 2.00" Lg.*
14 11473—463 Impeller Assembly
15 710-157 Hex Scr. 5/16-24x%" Lg.*
16 736-119 L-Wash. 5/16" Scr.*
17
18 11452—463 Hopper to Engine Mtg. Plate
Engine
19 11464—463 Engine Mounting Plate
20 712-123 Hex Nuf 5/16-24 Thd.*
21 736-119 L-Wash. 5/16" Scr.*
22 736-119 L-Wash. 5/16" Scr.*
23 712-123 Hex Nuf 5/16-24 Thd.*
24 726-221 Push Cap
25 7006 Fortiflex Bearing
Wheel Ass'y.—Comp.
26 8306-522
27
736-100 FI. Wash. .50" I.D.*
28 710-237 Hex Scr. 5/16-24 X. 62" Lg.*
29 712-429 Elastic Stopaut 5/16-18 Thd.
30 710-237 Hex Scr. 5/16-24 x .62" Lg.*
31 714-115 Cotter Pin Vs" Dia. x 1.00" Lg.*
32 736-192 FI. Wash. .531" I.D. x .937 O.D.
X .09
33 11459—463 Flail
34 711-564 Flail Spacer 23/32" Lg
35 711-578 Clevs Pin .50" Dia. x 3.0" Lg.
36 736-247 FI. Wash. .406" I.D. x 1.25"
O.D. Hdn.
37 736-21 7 L-Wash. %" Scr. Heavy Duty
38 710-151 Hex Scr. %-24x2.00" Lg. H.T.
39 11474—463 Flail Housing Ass'y.—Comp.
40 712-107 Hex Center L-Nut 'A-20 Thd.
41 1 1477—463 Upper Guide Extension Ass'y.
42 11478 Hinge Pin
43 726-111 Palnut 3/16" Dia.
44 712-109 Wing Nut Elastic 'A-20 Thd
Blade 45 1 1458—463
46 1 1475—463 Axle
*For faster service obtain standard nuts, bolts and washers locally. If these items canno" be obtained locally, order
by part number and size as shown on parts list.
(463—Top Flife Red) — When ordering parts, if color or finish is important, use the appropriate color code
shown at left. (e.g. Top Flife Red—1 1464 (463).)
Find us fast In the
The engine is not under warranty by the mower manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the "Yellow Pages" of
your telephone book under "Engines—Gasoline."
