MTD 244-650A - Manual (Page 7)

PARTS LIST FOR FIGURE 8 MODEL 244-650A
REF.
NO. PART
NO.
COLOR
CODE DESCRIPTION
NEW
PART
1 11460—463 Guide Extension Assembly
2 11472—463 Guide Extension
3 736-264 Flat Washer 5/16" Scr.*
4 712-429 Elastic Stopnut 5/16-18 Thd.
5 11481 —463 Hopper Assembly
6 710-621 Hex Scr. 5/16-18 X .50" Lg.*
7 736-119 Spring L-Wash. 5/16" Scr.*
8 11479—463 Clamp Rod Assembly
9 11454—463 Back-up Plate
10 11467—463 Inlet Guide AssembI y
11 712-429 Elastic Stopnut 5/16-18 Thd.
12 9966 Knob Ass'y.
13 736-264 FI-Wash. .50" Dia.*
14 11480 Stop Washer
15 712-429 Elastic Stopnut 5/16-18 Thd.
16 736-264 FI. Wash. .50" Dia.*
17 711-566 Chute Pivot Rod
18 712-107 Hex Center L-Nut 14-20 Thd.
19 710-289 Hex Scr. ’/4-20 x .50" Lg.*
*For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order
by part number and size as shown on parts list.
(463—Top Flite Red) • When ordering parts, if color or finish is important, use the appropriate color code
shown at left. (e.g. Top Flite Red—11464 (463).)
Find us fast in the
The engine is not under warranty by the mower manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the "Yellow Pages" of
your telephone book under "Engines—Gasoline."
