LIST FOR LOG SPLITTER MODELS 247-640A and 24640-7
..ef.
No.
Part
No.
Color
Code
Description
New
Part
Ref.
No.
Part
No.
Color
Code
Description
New
Part
1
710-0331
HexScr. 3/8-24x2.25” Lg.*
25
13291
Engagement Lever Ass’y.
N
2
13275
Cam Piate
N
26
738-0258
Shoulder Scr. 3/8-16 Thd.
3
727-0203
High Pressure Hose Ass'y.
27
13280
Strainer Tube Ass’y.
N
11.0” Lg.
N
28
727-0204
Return Hose
N
4
737-0155
Reducing Bushing
N
29
711-0169
Coilar
5
717-0364
Valve
N
30
734-0584
Wheel Ass’y. Comp.
6
736-0119
L.-Wash. 3/8” Scr.*
31
736-0237
FI.-Wash. .656 I.D.x I.OOTh d.
7
712-0241
Hex Nut 3/8-24 Thd.*
32
13276
Tank Ass’y. Complete
N
8
08118
Grip
33
751-0224
Breather Cap
N
9
737-0153
Return Elbow
N
34
727-0205
Inlet Hose
N
10
737-0154
Cylinder nipple .75”x4.5” Lg
. N
35
737-0151
Inlet Nipple
N
11
732-0342
Spring Clip
N
36
717-0363
Pump - Complete(bJ£R.ST£i^) N
12
732-0341
Cylinder Return Spring
N
37
737-0152
High Pressure Elbow
N
13
13304
Cylinder Ass’y.
N
38
710-0376
HexScr.5/16-18x 1.00” Lg
*
14
721-0159
‘‘0”-Ring
N
39
712-0267
HexNut5/16-18 Thd.*
15
13302
Push Cylinder Ass’y.
N
40
13295
Coupl ing Support Brkt. Ass’y ^ N
13314
Spring Hook Ass’y.
N
41
714-0114
Sq. Key 1/4”x2.00” Lg.*
7
726-0173
Hose Clamp
N
42
710-0237
HexScr. 5/16-24X .62” Lg.*
18
749-0251
Engagement Handle
N
43
710-0528
Hex Scr. 5/16-18x1.25”Lg.
*
19
13310
Cylinder Holding Plate
N
44
Engine
20
736-0119
L-Wash. 5/16” Scr.*
45
717-0374
Flexible Coupling Comp.
N
21
710-0528
Hex Scr. 5/16-18x1.25” Lg.
46
714-0507
Cotter Pin 3/32” Dia.X .75”
Lg.*
22
13305
”I”-Beam Ass’y. Comp.
N
47
736-0142
Fl.-Wash. .28I.D.
x
.50”O.C
).
23
13312
Return Collar Ass’y.
N
48
711-0660
Clevis Pin
N
24
710-0494
Sq.Hd.SetScr.5/16-18x .38”
_________________________________________________________________________
Lg.
LL_
‘For faster service obtain standard nuts, bolts and washers locally. If these Items cannot be obtained locally,
order by part
number and size as shown on parts list.
The engine is not under warranty by the log splitter manufacturer. If repairs or service is needed
on the engine, please contact your neorest authorized engine service outlet. Check the "Yellow
Pages” of your telephone book under "Engines — Gasoline.”
