SECTION 5: SPECIFICATIONS
C ontents
• Specifications • Warranty
Specifications
S no -T hro
Model Number 938006 938007 938008 938009
938301 938303
Description SS322 SS522 SS322E SS522E
Engine
Engine Power - HP (KW) - 2 Cycle 3 (2.24) 5 (3.73) 3 (2.24) 5 (3.73)
Engine Operating Fast Idle Speed - RPM 4300 3600 4300 3600
Engine Displacement - in (cc) 6.0 (98) 8.46(139) 6.0 (98) 8.46(139)
Fuel See Engine Manual for type and grade
Fuel to Oil Mix 50:1
Fuel Tank Capacity - qt (Liters) 1.2 (1.1)
Fuel Filter Neck Inside Dia. - in (cm) 2.8 (7.1)
120V Electric Start Option Yes Installed
|
Snow Clearing Width - Cu. in (cm) 22 (56)
Snow Throwing Distance - ft (meters) 3-30 (0.9-9.1)
Chute
Chute Rotation Angle 220°
Chute Rotation Control at Handlebar No 007Yes/303 No No Yes
Chute Inside Dia - in (cm) 6.0(15.2)
Handlebar
Operator Present Impeller Clutch/Brake Control Yes
Folding Handlebar Yes
Handlebar Adjustable For Height Yes
Size & Weight
Handlebars Max. Extended Height - in (cm) 40.8(104)
Minimum Folded Height - in (cm) 25.8 (65.5)
-----------------------------------------------------
X.
---------- ^-------------------------------------------------- 1
Length - in (cm) 43.2(110)
Minimurn Folded Length - in (cm) 34.5 (87.6)
Width - in (cm) 22 (56)
Weight - lbs (Kg) 58 (26.4) 73 (33.2) 60 (27.2) 1
75 (38.5)
1
Impeller
Impeller Dia - in (cm) 9.0 (23)
Impeller Speed - RPM 1120 1100 1120 1
1100 1
Drive Belt 3L Section
Single “V” Yes
Construction Raw Edge
Material Kevlar Cord
Wheels
Wheel Size - in (cm) 7.0 X 1.5(18x3.8)
18
Ariens® Sno-Thro® Orig. 4/96
