Ref. No. Description Part No. Qtv.
1 .................. Screw, 10-16 X 1-1/2“, Panhead*...................................................................................... 1750608........................ 1
2 ..................Switch, Engine Ignition.......................................................................................................1983718........................ 1
Bracket Switch..................................................................................................................1981012001..................1
3 ................. Handlebars, Upper, with grips and decals......................................................................... 1981046........................ 1
3A....................Grip, Handlebar..................................................................................................................1983728.........................2
4
..................Spacer, rectangular rubber............................ .................................................................... 1983649.......................1
5 ..................Wire, Engine ignition, “On/Off............................................................................................ 1909812........................1
6 ..................Ref. Number Not Used
7 ..................Lever and Cable Assembly, Throttle..................................................................................1986201........................1
8 ................. Bolt, Carriage, 5/16"-18 x 2".............................................................................................. 1731025.........................2
9 ................. Rat Washer, 5/16” I.D......................................................................................................... 1107382........................6
10 ............... Knob, Handlebar................................................................................................................ 1763767........................ 2
11 ............... Handlebar, Lower Right..................................................................................................... 1984509001..................1
12 ............... Handlebar, Lower Left........................................................................................................1984510001..................1
13 ............... Washer, Rat #8*.................................................................................................................1187293........................1
14 ............... Screw, Hex Head #8 - 32 x 1“ *......................................................................................... 1983661........................1
15 ................ Engine, Tecumseh TC-200-2106 (Available through Local Tecumseh Service Dealers)
16 ............... Locknut, 1/4"-20’'................................................................................................................1817146...................... 10
17 ............... Bolt, Hex Head 1/4"-20 x 5" *.............................................................................................1983663........................ 2
18 ............... Hairpin Cotter..................................................................................................................... 1185590........................ 2
19 ............... Clutch Rotor....................................................................................................................... 1909487........................1
20 ............... Ref. Number Not Used
21 ................Drag Stake......................................................................................................................... 1981014001..................1
22 ............... Clevis Pin, 5/16" x 7/8".......................................................................................................1983723........................1
23 ............... Drag Stake Bracket............................................................................................................1981010001..................1
24 ............... Hairpin Cotter..................................................................................................................... 1703011 .......................1
25 ............... Tine, Outer, Right-Hand Side.............................................................................................1984430........................1
26 ............... Tine, Inner, Right-Hand Side............................................................................................. 1984429........................1
27 ............... Bolt, 1/4"-20 X 1-1/8“ * (drag stake to transmission)..........................................................1983658........................ 3
28 ............... Tine Cover (with Decals)....................................................................................................1904124........................1
29 ............... Plate, Rear, Tine Cover..................................................................................................... 1981022010..................1
29A.................. Rock Shield........................................................................................................................ 1981018010..................1
30
............... Screw, #10-32 X 1/2“, self-tapping (for rear tine cover plate)............................................ 1983662........................ 2
31 ............... Lockwasher, 1/4“ *............................................................................................................. 1100241 ....................... 4
32 ............... Bolt, 1/4"-20 X 2“ (Grade 5)............................................................................................... 1100807........................ 4
33 ............... Bolt, 1/4"-20 X 7/8” (Grade 5)............................................................................................ 1111600........................ 5
34 ............... Ref. Number Not Used
35 ............... Tine, Inner, Left-Hand Side................................................................................................1984427........................1
36 ............... Tine, Outer, Left-Hand Side............................................................................................... 1984428....................... 1
37 ............... Ref. Number Not Used
38 ............... Clutch Drum and Hub........................................................................................................ 1909486........................1
' Denotes items usually available from a quality hardware store as well as from the Factory.
Decals
Product Name Logo Decal (on front lip of tine cover)...................................................... 1984529........................1
Caution Decal (located on rear of tine cover)................................................................... 1983094........................1
Warning Decal (located on rear of tine cover).................................................................. 1983095........................1
Engine / Tine Speed Decal (located on the right handlebar)............................................1983096........................1
Engine Ignition Switch Identification Decal (on right handlebar)............................... .......1983097....................... 1
Kits and Accessories
Tine Spacers (install when outer tines are off for cultivating)........................................... 1983648........................ 2
............. 1
............. 1
............. 1
............. 2
............. 1 Cup, Oil Measuring.............................................................................................................1983647.
Replacement Tines (ind. Ref. No.’s 25, 26, 35, 36).......................................................... 1982393.
Transmission Assembly......................................................................................................1909803.
Tie Strap, 6", nylon............................................................................................................. 1983727.
Tine Spacer Kit (incl. two 1983648)....................................................................................1981053.
