Audio Distribution System Crestron Adagio™ AADS
AADS Buttons and Ports (AADS-XM Shown)
10
23
20
21
2 4 3 11 12 13
1
5
6
9 8
18
19
14 15
17
24 26 28 29 30
25 27
22
7
16
Connectors, Controls, & Indicators
# CONNECTORS,
CONTROLS, &
INDICATORS 1
DESCRIPTION
1 SELECTION CONTROL Used to select rooms, sources, and radio
stations (when using tuner).
2 SELECT BUTTON The SELECT button confirms changes
made to AADS settings.
(Continued on following page)
10 • Audio Distribution System: Adagio AADS Operations Guide – DOC. 6458
