MODELS 12068, 12069, 12070, 12071, 12087, 12087C, 12088, 12088C, 12089, 120890,12090, 12090C
FORWARD INTERLOCK SYSTEM
(Figure 5)
REF
No.
PART
No.
DESCRIPTION
QTY.
REF
No.
PART
No.
DESCRIPTION
QTY.
1
2552
Engine Wire Harness Assy-forward
4
ET69-12
Grommet-for Kohler engine........
1
interlock system (Incl. one red
5
ET42-447
Screw-#8 Phillips Head, for Kohler
and one black wire, plug con-
engine...................................
1
nector, neutral switch and PVC
6
9205
Clip-for plug connector...............
1
tubing. Parts not available
7
9202
Tie-plastic.................................
1
separately..............................
1
8
2551
Handlebar Wire Harness Assy-
2
9971
Lockwasher-external tooth, 7/16“..
...1
(see page 2, Ref. No. 20).......
1
3
1186246
Nut-hex, 7/16"-20.....................
1
Note: Ref. No. 4 may also be obtained at a Tecumseh Engine
Authorized Service Center by ordering part no. 69-12. Ref. l\io.
5 may also be obtained at a Tecumseh Engine Authorized Ser
vice Center by ordering part no. 42-326.
