(3) Thread the needle thread in the order® to(g)(blue mark).
Threading of needle eye (g) becomes easier when the movable knife is set at the nonoperating position
(See figure on page 14 for movable knife non-operating position).
Wind thread around guide
when threading (g) as
shown in figure.
Tension discs
While holding thread with
finger, pass it between the
tension discs and pull thread
down to make certain it is
properly located in between
the tension discs.
• Lower needle bar when
threading (g) .
• Use tweezer to thread eye®.
• Draw about 5cm (2 inches)
of thread from needle eye.
(4) When needle thread is not correctly
threaded between the tension discs,
it will lie loose on the underside of
the material as shown in figure at
right.
Underside
