Placing bobbin case in shuttle, Thread guides "hook check, Spring – SINGER W8931 User Manual
Page 10
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

lo
PLACING BOBBIN CASE IN SHUTTLE
i'o
cover plate left of the aeedle.
\ bee 16, Fig. 1) Hold the bobbin case latch, (D:,
1 xg. 9, between the thumb and forefinger of the left
hand, with at least three inches of thread running
from the top the bobbin case to the right. Insert
and center the bobbin case on the stud of the
shutJe body,
{ Q j .
Be sure the bobbin case finger,
IS opposite the shuttle race notch, (A). Press
the boobin case (B) into the shuttle as far as pos-
sibie until latch, cauches on the center post of the
shuttle.
THEN release the bobbin case latch, fDh
pess bobbin case again after latch has been re
leased to^ make sure the bobbin case is locked
securely in place. Close the cover plate.
THREAD
GUIDES
"HOOK
CHECK
'J
SPRING
Pig. 10
