ADJUSTING THE TENSIONS
Always adjust tlie upper tension, with, the presser
foot down, as the tension is automatically released
when it is raised. To increase the tension on the
upper
thread,
turn
dial
(iigj
13)
clockwise,
or
toward you. To decrease, turn iaway from you. The
higher the number on the dial the tighter the ten
sion.
Before adjusting lower tension be sure that the ma
chine
is
threaded
properly.
When
necessary
to
change the bobbin tension, tum small screw (Fig.
14) on side of the bobbin case clockwise to tighten
counter-clockwise to loosen.
’
When
the
upper
and
under
tensions
are
properly
balanced, a perfect stitch will be formed with both
threads interlocking in fabric (|Fig. 15).
When the upper tension is too ti^ht, the lower thread
is pulled up over the upper thread which is lying
flat on the fabric.
When the under tension is too tifht, the upper thread
forms loops over the lower thread lying flat on the
fabric.
Upper thread tension too tight
Fig. 15
13 ^
Under thread tension too tight
