Fig. 9
PLACING BOBBIN CASE IN SHUTTLE
Raise needle bar to highest position, hnd. lift hinged
cover plate. Hold the bobbin case latch, (D), Fig.
9,
between
the
thumb
and
forefinger
of the
left
hand, with at least three inches of thread running
from the top of the bobbin case to thfe right. Insert
and
center
the
bobbin
case
on
th
shuttle body, (C). Be sure the bobfiin. case finger,
(E), is opposite the shuttle race notcir, (A). Press
the bobbin case (B) into the shuttle
sible until latch catches on the ceni
shuttle. THEN release the bobbin case latch, (D).
Press bobbin case again after latch has
to make sure the bobbin case is lo
in place. Close the cover plate.
