TROUBLE CHART
27
Trouble
Probable Cause
Correction
If machines
bind
Thread or lint in race way
1.- With take-up lever in highest position,
tilt head back on hinges and remove
bobbin case.
RACE
2. - Turn clamps downward and remove race
cover.
3. - Remove hook.
4. - Clean thread and lint from all parts, in
cluding race.
5. - Run a drop of oil along rim of hook.
6
. - Replace hook, then race cover. Snap
clamps into place.
7. - Grasp threaded bobbin case by latch
and replace, fitting tongue into notch of
race cover.
L
