the bobbin thread
Your sewing machine uses two threads to form a stitch. The upper thread comes from the
spool and Is threaded through the eye of the needle. The lower thread comes from the bob­
bin. Wind the bobbin before threading the machine.
WINDING THE BOBBIN
Preparation Steps
1. Raise the presser foot and turn hand wheel
toward you until needle is in highest po­
sition.
2. Loosen hand wheel knob A by turning it to­
ward you with the right hand while holding
Hand wheel with the left hand.
3. Open slide plate and lift out bobbin.
4. Place spool pin felt on pin.
Winding Steps
Pass Thread
Through Hole
in Bobbin
B
f --------
V ^ 7
* Place thread spool on spool pin with thread
retaining silt B on top. (Break paper at the
end of spool if necessary). If you are using
; a tube of thread affix spool pin extension
^ to spool pin to ensure even flow of thread.
♦ Lead thread around bobbin winder tension
; disc C and through small hole in bobbin
- from inside out. •
• Place bobbin on spindle and push bobbin
to right to engage bobbin winder.
• Hold thread end as shown and start the ma­
chine. Cut off thread end after a few colls
have been wound.
• When required amount of thread has been
wound (winding will stop when bobbin is
full), stop the machine and cut connecting
thread.
• Push bobbin to left and remove bobbin from
spindle.
• Hold hand wheel and tighten hand wheel
