ai BASIC OPERATION
1 Open the back cover.
2 Load the film. Pull out the film leader
end to reach the [FILM ^ ] mark O-
If there Is dirt on the film detector O,
the film cannot be wound properly.
3 Close the back cover.
The film automatically advances to the
first frame.
If “E” blinks on the LCD panel, repeat step 1 -3
to load the film properly.
4 Open the lens protector to turn the
switch ON.
5 Adjust the focus frame in the middle of
the viewfinder to optimum clarity by
diopter adjustment lever.
Compose your subject by using the
zoom button and focus on the subject
within the autofocus frame.
6 Press the shutter release button
halfway down to confirm the focus with
green lamp lights on, and press the
shutter release button completely to
take a picture. The flash automatically
discharges in low light.
7 The film will be rewound automatically
after you have exposed the last frame
of the roll.
8 Unload the film after confirm “0” blinks
on the LCD panel.
• When the lens protector is opened, the lens
slightly extends.
• When the camera is left unused for 3
minutes with the power on, the zoom lens
automatically retracts to 38 mm to prevent it
from damage.
• When the camera is unused for 5 minutes
in
the remote control mode, the zoom lens will
be retracted to 38 mm position and cancel
the remote control mode.
