Always order by Part Number - not by Key Number
FIGURE 1 PARTS LIST
PARTS LIST FOR CRAFTSMAN DRILL PRESS MODEL NO. 113.21371 & 113.213710
Key
No.
Part
No. Description
1 71097 Pulley Assembly (See Figure 2)
2 STD 541110 *Nut, Hex 10-32
3 71046 Connector, Wire 14-18
4 STD 571812 'Pin, Roll 3/16
5 71163 Saddle, Wire
6 STD 551210 ' Lockwasher, internal No. 10
7 STD 551208 Lockwasher, Int. No. 8
8 169689 'Screw, Type 23 Pan Hd. 6-32 x 5/8
9 71092 Plate, Rear Cover
10 STD 610805 'Screw, Type A Pan SI. No. 8 x 1 / 2
1 1 71170 Bracket
12 37818 Relief, Strain
13 STD 601103 'Screw, Type 23 Pan SI. 10-32 x 3/8
14 71056 Outlet
15 STD 610802 'Screw, Type A Pan SI,No. 8 x 1/4
16 71088 Socket, Bulb
17 139377 'Screw, Set Cone Pt, 5/16-18 x 1-1/4
18 STD 541231 'Nut, Hex 5/16-18
19 37837 Wrench, Hex "L" 5/32
20 Guard Assembly {See Figure 2)
21 71138 Belt, V
22 9411963 'Screw, Set Soc.Cup Pt.5/16-18 x 1/2
23 71065 Pulley, Motor
24 STD 532507 'Bolt, Carriage, 5/16-18 x 3/4
25 71164 Mount, Motor
26 STD 551031 'Washer, 11/32
27 71165 Tie, Wire
28 71151 Clamp, Adjusting Rod
29 71153 Rod, Adjusting
30 71152 Tip, Adjusting Rod
31 60226 Screw, Adjusting Rod
32 71166 Cord with Plug
33 71167 Panel, R.H. Trim
34 145372 'Screw, Drive Rd.Hd.No. 4 x 1/4
35 60307 Grip
36 STD 533115 'Bolt, Carriage 5/16-18 x T1/2
37 71050 Collar
38 38626 Lock, Barrel
Key Part
No. No. Description
39 71098 Scale, Depth
41 60193 'Pin, Roll 3/16
42 71074 Hub Assembly (Includes Key Nos. 43 & 44)
43 38989 Spring
44 27617 Pin
45 71139 Rod
46 38546 Knob
47 60260 Grip
48 60265 Handle, Lock
49 38627 Lock, Barrel
50 71136 Tube, Column
51 38452 Washer, Fiber
52 38631 Lock, Barrel
53 71168 Table
54 100163 Bolt, Hex Hd. 1/2-13 x 2-1/2
55 71101 Base
56 71178 Key, Drill Chuck
57 38623 Chuck, Drill
58 71075 Spindle Ass'y., Stop (See Figure 3)
59 71149 Shoe, Depth Gage
60 60191 Screw, Thumb
61 71140 Pointer, Depth Gage
62 71082 Nut, Stop
63 71169 Panel, L.H. Trim
64 71161 Handle
65 38632 Lock, Barrel
66 318595 Lockwasher, Int. C'Sink No. 6
67 71146 Cover, Switch Plate
68 60256 Key, Switch
69 133423 'Screw, Mach.Flat Hd.6-32 x 3/8
70 71086 Plate, Switch Mounting
71 71144 Switch
72 71145 Switch
73 71099 Head, Drill Press (Includes Key No. 74)
74 132124 'Screw Fil.Hd. 10-32 x 3/4
75 70047 tMotor, 1/2 H.P. 1725 RPM
71189 Owners Manual (Not Illustrated)
71175 Bag Assy., Loose Parts (Not Illustrated)
'Standard Hardware Item - May be Purchased Locally t Stock Item - May be secured through the hardware dept,
of most Sears Retail or Catalog Outlets.
