SEARS CRAFTSMAN 8 H.P. ENGINE MODEL 143.978005 FOR
CHIPPER-SHREDDER MODEL 247.775860
Key
No. Part
No.
Description Key
No. Part
No.
Description
261 650788 Screw, 5/16-18
X
3/4” 307 35499 “0”-Ring
262 29747B Screw, Torx T-40, 5/16-24 x 21/32” 308 35540 Fill Tube Clip
264A 650802 Screw, 1/4-20 x 5/8” 310 36205 Dipstick
265 33272B Cylinder Head Cover 325 29443 Wire Clip
275 34185B Muffler 327 35392 Starter Plug
276 31588 Locking Plate 339 35880 Spacer
277 650729 Screw, 5/16-18x3-3/16” 340 34259 Fuel Tank Bracket
277A 651036 Screw, 5/16-18x3-31/32” 341 34258A Fuel Tank Bracket
278 36908 Heat Shield Spacer 342 30063 Screw, TorxT-30, 1/4-20 x 1/2”
280 36799A Heat Shield 370C 35274 Oil Instruction Decal
281 33013 Starter Bubble Cover 370J 35703 Throttle Decal
282 650760 Screw, 8/32 x 3/8” 380 632351 Carburetor (Incl. 184)
285 35985B Starter Cup 390 590704 Recoil Starter
287 29752 Nut& Lock Washer, 1/4-28 400 36450B Gasket Set (Incl. Items Marked PK in Notes)
290 30962 Fuel Line Incl. part#’s 27272A, 27896A, 27915A, 29673,
292 26460 Fuel Line Clamp 33263, 33629, 34698A, 35262A, 36448
298 650665 Screw, 1/4-15
X
3/4” 416 34479A Spark Arrester Kit
300 34186A Fuel Tank (Incl. 292 & 301) 800
-
Replacement Engine.
301 36246 Fuel Cap 900
-
Replacement SB 758321, order from 71 -999
305 35554 Oil Fill Tube
24
