SEARS CRAFTSMAN 8 H.P. ENGINE MODEL 143.978005 FOR
CHIPPER-SHREDDER MODEL 247.775860
Key No. Part No. Description Key No, Part No. Description
RPM Low 1700 92 650880 Lock Washer
-
RPM High 3450 to 3750 93 650881 Flywheel Nut
1 35385 Cylinder (Incl. 2 & 20) 100 35135 Solid State Ignition
2 27652 Dowel Pin 101 610118 Spark Plug Cover
4 -
Oil Drain Extension 102 650872 Solid State Mounting Stud
5 30969 Extension Cap 103 651007 Screw, Torx T-15, 10-24 x 15/16”
15 30699C Governor Rod (Incl. 15A & 15B) 110 35187 Ground Wire
15A 30700 Governor Yoke 119 36448 Cylinder Head Gasket
15B 650494 Screw, 6-40
X
5/16” 120 36449 Cylinder Head
16 33454 Governor Lever 125 27878A Exhaust Valve (Std.) (Incl. 151)
17 29916 Governor Lever Clamp 27880A Exhaust Valve (1/32” O.S.) (Incl. 151)
18 651028 Screw, TorxT-15, 8-32 x 3/8” 126 34035 Intake Valve (Std.) (Incl. 151)
19 34663 Speed Control Spring 34036 Intake Valve (1/32” O.S.) (Incl. 151)
20 35319 Oil Seal 127 650691 Washer
25 36460 Blower Housing Baffle 128 650690 Belleville Washer
26 650561 Screw, 1/4-20 x 5/8” 130 650694A Screw, 5/16-18
X
2”
28 30322 Lock Nut, 8-32 130B 650273 Screw, 5/16-18
X
5/8”
30 36283A Crankshaft 135 33636 Resistor Spark Plug (RJ-17LM)
35 29826 Screw, 10-32
X
3/4” 139 33369 Governor Gear Bracket
36 29918 Lock Washer 140 650838 Screw, 10-24
X
1/2”
37 29216 Lock Nut, 10-32 149 27882 Valve Spring Cap
38 29642 Retaining Ring 149A 35862 Valve Spring Cap
40 34552 Piston, Pin, And Ring Set (Std.) 150 27881 Valve Spring
34553 Piston, Pin, And Ring Set (.010” O.S.) 151 32581 Valve Spring Keeper
34554 Piston, Pin, And Ring Set (.020” O.S.) 169 27898A Breather Gasket
41 34329A Piston & Pin Ass’y. (Std.) (Incl. 43) 170 28423 Breather Body
34330A Piston & Pin Ass’y. ¿010” O.S.)(lncl. 43) 171 28424 Breather Element
34331A Piston & Pin Ass’y. (.020” O.S.) (Incl. 43) 172 28425 Valve Cover
42 34332 Ring Set (Std.) 173 35350 Breather Tube
34333 Ring Set (.010” O.S.) 174 650128 Screw, 10-24 x 1/2”
34334 Ring Set ¿020” O.S.) 178 29752 Nut and Lock Washer, 1/4-28
43 27888 Piston Pin Retaining Ring 182 30088A Screw, 1-4-28 x 1”
45 36897 Connecting Rod Ass’y. (Incl. 47 & 49) 184 33263 Carburetor to Intake Pipe Gasket
47 651033 Connecting Rod Bolt 185 34707 Intake Pipe
48 34034 Valve Lifter 186 34667 Governor Link
49 36896 Oil Dipper 200 34677 Control Bracket (Incl. 19, 203 & 204)
50 35375 Camshaft (MCR) 203 31342 Compression Spring
60 33273A Blower Housing Extension 204 651029 Screw, Torx T-10, 5-40 x 7/16”
65 650128 Screw, 10-24 x 1/2” 206 610973 Terminal
69 35262A Cylinder Cover Gasket 207 33878 Throttle Link
70 35376 Cylinder Cover (Incl. 71,75 & 80) 209 650821 Screw, 10-32
X
1/2”
71 35377 Crankshaft Bushing 215 35882 Control Knob
72 28582 Oil Drain Plug 223 650378 Screw, TorxT-30, 5/16-18 x 1-1/8”
75 35319 Oil Seal 224 27915A Intake Pipe Gasket
80 31845 Governor Shaft 238 28820 Screw, 10-32
X
1/2”
81 30590A Washer 239 27272A Air Cleaner Gasket
82 35378 Governor Gear Ass’y. (Incl. 81) 240 33266 Air Cleaner Body
83 30588A Governor Spool 242 33267 Air Cleaner Bracket
84 29193 Retaining Ring 245 33268 Air Cleaner Filter
86 650833 Screw, 1/4-20
X
1-3/16” 245A 35881 Air Cleaner Filter
87 650832 Screw, 1/4-20
X
1-11/16” 250 33269A Air Cleaner Cover
89 32589 Flywheel Key 251 650513 Wing Nut, 1/4-20
90 611090 Flywheel 260 36250 Blower Housing
23
