6. DON’T USE IN DANGEROUS ENVIRONMENT
Don't use power tools In damp or wet locations, or expose
them to rain. Keep work area well illuminated.
7. KEEP CHILDREN AWAY
All visitors should be kept a safé distance from work area.
8. MAKE WORKSHOP KID PROOF
with padlocks, master switches, or by removing starter keys.
9. DON’T FORCE TOOL
It will do the job better and be safer at the rate for which it
was designed.
10. USERIGHTTOOL,
Don’t force tool or attachment to do a job for which it was not
designed.
11. WEAR PROPER APPAREL
No loose clothing, gloves, neckties, rings, bracelets, or
jewelry to get caught in moving parts. Nonslip footwear is
recommended. Wear protective hair covering to contain long
hair.
12. ALWAYS USE SAFETY GLASSES
Also use face or dust mask if cutting operation is dusty.
Everyday eyeglasses only have impact resistant lenses. They
are NOT safety glasses.
13. SECURE WORK
Use clamps or a vise to hold work when practical. It’s safer
than using your hand and frees both hands to operate tool.
14. DON’T OVERREACH
Keep your proper footing and balance at all times.
15. MAINTAIN TOOLS IN TOP CONDITION
Keep tools sharp and clean for best and safest performance.
Follow instructions for lubricating and changing accessories.
16. DISCONNECT TOOLS FROM POWER SOURCE
before servicing and when changing accessories such as
blades, bits, cutters, or when mounting and re-mounting
motor.
17. AVOID ACCIDENTAL STARTING
Make sure switch is in "OFF” position before plugging in
cord.
18. USE RECOMMENDED ACCESSORIES
Consult the owner’s manual for recommended accessories.
Use of improper accessories may be hazardous.
19. NEVER STAND ON TOOL
Serious injury could occur if the tool is tipped or if the cutting
tool is unintentionally contacted.
20. CHECK DAMAGED PARTS
Before further use of the tool, a guard or other part that is
damaged should be carefully checked to ensure that it will
operate properly and perform its intended function - check
for alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other conditions that
may affect its operation. A guard or other part that is damaged
should be properly repaired or replaced.
21. DIRECTION OF FEED
Feed work into a blade or cutter against the direction of
rotation of the blade or cutter only.
22. NEVER LEAVE TOOL RUNNING UNATTENDED. TURN
POWER OFF. Don’t leave tool until it comes to a complete
stop.
The operation of any power tool can result in foreign objects
being thrown into the eyes, which can result in severe eye
damage. Always wear safety goggles complying with ANSI Z87.1
(shown on Package) before commencing power tool operation.
Safety Goggles are available at Sears retail or catalog stores.
TABLE OF CONTENTS
GENERAL SAFETY RULES FOR POWER TOOLS..................... 2, 3
UNPACKING AND CHECKING CONTENTS.............................. 4
SAFETY RULES FOR JOINTER-PLANER..................................5
ASSEMBLY.................................................................... 5-7
Depth of Cut Hand Knob................................................. 5
Chip Deflector............................................................... 5
Checking Cutter Blades.................................................. 6
Fence........................................................................ 6, 7
Fence Extension............................................................ 7
INSTALLING THE JOINTER-PLANER..................................... 8
CONTROLS AND ADJUSTMENTS....................................... 8-9
Depth of Cut Hand Knob.............................................. 8, 9
Fence Adjustment..........................................................9
Cutter Guard................................................................. 9
ON/OFF Switch.............................................................. 9
BASICJOINTER-PLANER OPERATION............................ 10-12
Feeding the Workpiece.................................................10
Using Holddown/Push Blocks........................................ 11
Beveling, Chamfering..............................................11,12
Using a Wet/Dry Vac................................................... 12
MAINTENANCE........................................................... 12, 13
Timing Belt Replacement .............................................12
Cutter Guard Return Spring.......................................... 12
Blade Replacement and Adjustment.............................. 13
General Maintenance................................................... 13
REPAIR PARTS............................................................14, 15
TROUBLESHOOTING....................................................... 16
How to Order Replacement Parts.................................. 16
