CRAFTSMAN 5-1/8 INCH JOINTER-PLANER MODEL No. 149.236320
PARTS LIST
Oi
REF.
NO.
PART NO. DESCRIPTION QTY. REF.
NO.
PART NO. DESCRIPTION QTY.
1 4550-001-70 Base 1 40 2292.68 Switch Key (Order for Key Only) 1
2 4550-011-70 Infeed Table 1 41 STD511007 #10-24 X 3/4 Pan Hd Mach Screw 6
3 E2292.75 Rocker Link Hinge 4 42 STD551010 #10 Flat Washer 5
4 1791.01 11/32 ID X 9/16 OD X 1/32 Washer 4 . 43 4550-120-70 Guard Return Spring 1
5 1727.01 *1/4-20x1-1/4 Socket Set Screw 2 44 2292.36 Guard Spacer 1
6 STD541025 1/4-20 Hex Nut 2 45 4550-039-70 Cutterguard 1
7 4550-050-70 Hand Knob 1 46 2292.34 Danger Plate (Order for Label Only) 1
8 STD551237 3/8 External Tooth Lock Washer 1 47 2292.51 .260 ID X .440 OD Wave Washer 1
9 STD541237 3/8 Hex Jam Nut 1 48 2292.50 1/4-20 X 1/2 Shoulder Bolt Slotted 1
10 4550-051-70 Table Screw 1 49 4550-012-70 Outfeed Table 1
11 2292.59 Table Spring 1 50 2292.16 Fence Bracket 2
12 2292.46 8MM Shaft E Clip 4 51 STD315205 10MM X 30MM Ball Bearing, Double Seals 2
13 4550-090-90 Cutterhead Assembly, Includes Ref Nos 14-18 1 52 2292.48 10MM Shaft Retaining Ring 1
14 2292.27 1/4-20 X 1/2 Socket Button Hd Screw 6 53 STD551025 1 /4 Flat Washer 4
15 4550-093-70 Blade Clamp 2 54 STD551125 1/4 Split Lock Washer 4
16 4550-092-70 Blade 2 55 STD522507 1/4-20 X 3/4 Hex Hd Cap Screw 4
17 4550-091-70 Cutterhead 1 56 STD581018 3/16 Shaft E Clip 2
18 STD502505 1/4-20 X 1/2 Socket Set Screw 3 57 4550-121-70 Detent Spring 2
19 4550-044-90 Chip Chute/Baffle Assembly 1 58 4550-162-70 Stop Pin 2
20 STD551210 #10 External Tooth Lock Washer 7 59 4550-161-70 Tilt Indicator 2
21 STD511003 #10-24 X 3/8 Pan Hd Mach Screw 7 60 4550-020-70 Fence 1
22 STD503105 5/16-18 X 1/2 Socket Set Screw 4 61 1699.10 *#8-32 X1/2 Flat Head Mach Screw 6
23 1714.02 1/4-20 X 3/4 10MM Hex Head Screw 4 62 4550-163-70 Fence Segment 2
24 STD610805 #8 X 3/8 Type B Pan Hd Screws 1 63 1791.02 9/32 ID X 17/32 OD X 1/8 Washer 2
25 STD510805 #8-32 X 1/2 Pan Hd Mach Screw 4 64 2292.19 1/4-20 X 1 Lock Knob 2
26 STD551208 #8 External Tooth Lock Washer 4 65 STD551008 #8 Flat Washer 6
27 4550-220-90 Motor Assembly, Includes Ref Nos 28-31 1 66 STD541008 #8-32 Hex Nut 6
28 4550-046-70 Motor Housing 1 67 4550-040-70 Rear Cover 1
29 4550-221-00 Motor (Northland (#73523) 1 68 2292.13 Chip Deflector 1
30 STD501002 #10-24 X 5/16 Socket Set Screw 2 69 2288.00 5/32 Hex Key (Allen Wrench) 1
31 2292.21 Motor Pulley 1 70 2292.44 2-1/2 Male, 1-1/4 Female Vacuum Adapter 1
32 STD522505 1/4-20 X 1/2 Hex Flange Screw 3 71 2292.47 Push Blocks (Order No. 2299) 2
33 2292.64 Motor Bracket 1 72 2292.66 6'10" Long 18/3 SJT Cord 1
34 2292.69 3/16 Cable Clamp, Heyco #3303 2 73 2292.10 Strain Relief Bushing (Heyco #1214) 1
35 2292.32 XL120 X 3/8W X 12 Timing Belt 1 74 STD511005 #10-24 x 1/2 Pan Hd Mach Screw 2
36 2292.29 Machine Pulley 1 75 1699-013-00 #8x1/4 Thread Forming Screw 1
37 4550-094-70 Cutterhead Shaft 1 - 4550-250-00 Sears Craftsman Label (Not Illustrated) 1
38 4550-041-70 Front Cover 1 - 4550-252-00 Owners Manual (Not Illustrated) 1
39 2292.67 DPST Switch (Includes Ref No 40) 1 - 2292.57 Parts Bag (Not Illustrated) 1
— 2105.39 Plastic Cable Tie (Not Illustrated) 1
•Standard Hardware Item - May be Purchased Locally.
