SERVICE AND ADJUSTMENTS

TO REMOVE CABLES, REVERSE ORDER -

» BLACK cable first from chassis and then from the fully

charged battery.

» RED cable last from both batteries.

POSmVS TERMINAL

NEGATIVE TERMINAL

CHASSIS -

POSITIVE

TERMINAL

/ ■

'V: I L - ■ ■ '■

jNs'

CABLES

CHARGED

battery

NEGATIVE

TERMINAL

FIG- 30

TO REPLACE HEADLIGHT BULB

" Raise hood.

® Futi bulb holder out ot the hole in the backside of the

grill.

® Replace bulb in holder and push bulb holder securely

back into the hole in the backside of the grill

« Close hood.

INTERLOCKS AND RELAYS

Loose or damaged wiring may cause your tractor to run
poorly, stop running, or prevent it from starting.

® Check wiring. See electrical wiring diagram in the

Repair Paris section of this manual.

TO REPLACE FUSE

Replace with 30 amp automotive-type plug-tn fuse The

fuse holder is located behind the dash,

Mu ioM Ü JA ^1%«

№ * i

it IA ■

111*4. i it Jlk ^ i*i* ll H ft V/

TO REMOVE HOOD AND GRILL ASSEMBLY

(See Fig. 31)

•

Raise hood.

» Unsnap headlight wirb connector.

• Stand in front of tractor. Grasp hood at sided, tilt toward

engine and lift otf of tractor*

FIG. 31
