Carrier 73Y - Manual (Page 3)

Table 1 — Physical and Electrical Data (Single Phase, 60 Hz) — 1993
MODEL
73
CASING
(See
Table 6)
CAPACITY (Btuh)* R-22
CHG
(oz.
± .05)
WET
BULB
AtF
NAMEPLATE
Cooling Heating Volts
Voltage
Range
Amps Watts EER
(DOE)
PF
(%) Cool Heat Cool Heat
XHA101D 305 9,100 5,200 29 5 103 115 127-104 9.0 16 1 1020 1840 9.0 98
XCA121D 305 12,000 — 37 5 10.0 115 127-104 105 - 1200 - 10.0 99
XCA123D 305 12,000/11,600 - 37 5 125 230/208 253-187 5 2 / 5 5 - 1180/1140 - 10 2/10.2 98/99
XHA123D 305 12,000/11,600 9,200/ 7,600 37.5 12.5 230/208 253-187 5 2/ 5.5 13.4/12 3 1180/1140 3080/2540 10.2/10 2 98/99
XCA153D 305 15,000/14,700 - 38 24 1 230/208 253-187 6 5/ 7.0 - 1470/1440 - 10 2/10.2 97/99
XHA153D 305 15,000/14,700 14,600/11,800 38 97 230/208 253-187 6 5 / 7 0 20.9/19 0 1470/1440 4790/3950 10 2/10.2 98/99
XHA173D 305 17,100/16,700 16,300/12,900 38 97 230/208 253-187 7 9/ 8.5 22 7/20.8 1800/1750 5220/4320 9 5/ 9.5 99/98
XCA183D 305 17,800/17,500 - 38 24.6 230/208 253-187 8.2/ 8 9 - 1870/1840 - 9.5/ 9 5 99/99
YCA213D 405 21,000/20,800 — 47 21.8 230/208 253-187 10 4/11.3 - 2290/2260 - 9 2/ 9.2 96/96
YCA213P 405 21,000/20,800 — 47 21.8 230/208 253-187 10.4/11.3 - 2290/2260 - 9 2 / 9 2 96/96
YCA243D 405 23,500/23,000 - 51 24.1 230/208 253-187 12.0/12.7 - 2670/2610 - 8 8/ 8.8 97/99
YCA243P 405 23,500/23,000 - 51 24.1 230/208 253-187 12 0/12.7 - 2670/2610 - 8 8 / 8 8 97/99
MODEL
73
CAPACITOR
(See Table 5)
FAN MOTOR
COMPRESSOR
(See Table 2)
THERMISTOR
(See Table 4)
HEATER
ASSEMBLY
(See Table 3)
CAPILLARY
(See Tables 7 and 8)
Carrier
Part Number
FLA Data Insertion
Number
of Tubes
XHA101D RC-1 25901023 1 88 H-1 Z-1 VI CD-4 CI-1 1
XCA121D RC-1 25901023 1.88 H-2 Z-1 - CD-6 CI-1 2
XCA123D RC-1 25901026 0.98 H-3 z-1 - CD-6 CI-1 2
XHA123D RC-1 25901026 0 98 H-3 z-1 V2 CD-6 CI-1 2
XCA153D RC-1 25901031 0 99 D-1 z-1 - CD-I CI-1 3
XHA153D RC-1 25901031 0 99 D-1 z-1 V3 CD-I CI-1 3
XHA173D RC-2 25901018 1.24 D-3 z-1 V4 CD-3 CI-1 3
XCA183D RC-2 25901018 1.24 D-3 z-1 - CD-3 CI-1 3
YCA213D RC-2 25901024 1.54 D-2 z-1 - CD-2 CI-1 3
YCA213P RC-2 25901024 1.54 D-2 z-1 - CD-2 CI-1 3
YCA243D RC-3 25901024 1.54 T-1 z-1 - CD-5 CI-1 3
YCA243P RC-3 25901024 1 54 T-1 z-1 - CD-5 CI-1 3
LEGEND
AHAM — Association of Home Appliance Manufacturers
ANSI — American National Standards Institute
DOE — Department of Energy
EER — Energy Efficiency Ratio
FLA — Full Load Amps
PF — Power Factor
•Based on AHAM Standard RAC-1 and ANSI Z234 1
At — Entering wet-bulb temperature minus leaving wet-bulb temperature
based on 67 F room wet-bulb temperature and 95 F dry-bulb outside-air
temperature If conditions vary, wet-bulb At will vary
Table 2 — Compressors
KEY NUMBER
(See Table 1)
REPLACEMENT
PART NUMBER
OIL RECHARGE
(oz.)
VOLTS
(1 Ph, 60 Hz)
LRA FLA
D-1 P033-1521 13.0 230/208 33 2 59
D-2 P033-2221 23.0 230/208 50 0 9.1
D-3 P033-1821 13.0 230/208 38 0 74
H-1 P031-1004 9.1 115 48 3 8.6
H-2 P031-1103 9 1 115 54 0 160
H-3 P031-1122 9.1 230/208 26.3 4.8
T-1 P035-2522 183 230/208 63.0 107
LEGEND
LRA — Locked Rotor Amps
FLA — Full Load Amps
