Homelite Rotary Mowers - Manual (Page 7)

No. Description Part No. (M 00 Qty. No. Description Part No. Qty.
1 GUIDE-belt (R. H.) LM-16042-80 X X 1 22 WASHER-lock LM-09109-65 X X 3
2 GUIDE-belt, (L. H.) LM-16042-79 X X 1 23 NUT-hex LM-09169-50 X X 3
3 BOLT-rd.hd., 5/16-18x3/4 LM-09194-14 X X 10 24 CLIP-baffle LM-16015-58 X X 4
4 WASHER-flat, 5/16 LM-09176-42 X X 8 25 BOLT-rd.hd. LM-09169-43 X X 4
5 WASHER-lock LM-09173-56 X X 10 26 SCREW-hex hd. cap LM-09077-27 X X 4
6 NUT-hex, 5/lp x 18 LM-09173-72 X X 10 27 WASHER-flat LM-09173-77 X X
4
7 LEG ASSEMBLY-arbor cover (outer) LM-16042-77 X X 2 28 HOUSING-mower (42") LM-16028-38 X 1
8 LEG ASSEMBLY-arbor cover (inner) LM-16042-78 X X 4 HOUSING-mower (48") LM-16028-78 X
1
> 9 COVER-arbor (R. H.) LM-16042-75 X X 1 29 BAFFLE-mower (42") LM-16032-68 X 1
>
10 WASHER- flat LM-09182-64 X X 6 BAFFLE-mower (48') LM-16033-6S X 1
<
'J)
11 WASHER-lock LM-09169-64 X X 14 30 BOLT-rd.hd., 3/8-16 x 1 LM-09232-32 X 2
Tl C 12 NUT-hex LM-09166-22 X X 14 BOLT-rd. hd. LM-09221-10 X 2
33 s 13 COVER-arbor (L. H:) LM-16042-74 X X 1
c/> X 14 HOOK-mower lift LM-16064-93 X X 1 Accessories
o 15 WASHER-flat LM-09184-30 X X 1
u
m 16 WASHER-lock LM-09181-99 X X 1 TRANSFER-patent LM-16019-19 X X 1
> 17 NUT-hex LM-09182-13 X X 2 TRANSFER-caution LM-01749-36 X X 2
□ 18 CABLE ASSEMBLY-lift LM-16064-73 X X 1 DECAL-quadrant LM-16075-19 X X 1
C/5 m 19 PIN-cotter LM-09184-52 X X 1 PAINT-blue, 14 oz. spray can LM-16076-89 X X 1
> 20 GUARD ASSEMBLY-discharge LM-16033-62 X 1 PAINT-black, 12 oz. spray can 22772 X X 1
1”
Z
GUARD ASSEMBLY-discharge LM-16033-65 X
1
DECAL- OPEI LM-01729-80 X X 1
c
21 BOLT-round head LM-09221-10 X X 1
