Homelite Rotary Mowers - Manual (Page 5)

r No. Description Part No.
00
Qtj
CENTER ARBOR & HOUSING (notshown) LM-16075-82 X 1
CENTER ARBOR & HOUSING (notshown) LM-16075-83 X 1
Includes: (each)
1 ARBOR TUBE ASSEMBLY-center LM-16022-59 X X 1
2 ^ BEARING LM-01082-02 X X 2
3 SPACER LM-16022-65 X X 1
4 ARBOR ASSEMBLY LM-16073-66 X X 1
5 WASHER-special LM-01084-72 X X 2
6 SHEAVE-mower spindle LM-16028-81- X X 1
7 WASHER-flat LM-09250-84 X X 1
8 SHEAVE-mower LM-16076-38 1
SHEAVE-mower LM-16076-37- X 1
9 KEY-woodruff LM-09183-12 X X 2
10 NUT-jam hex lock LM-16070-21 X X 1
11 SCREW-hex hd. cap, 7/16-20 x 1-1/2 LM-09280-66 X X 1
12 WASHER-lock, 7/16 LM-09181-99 X X 1
13 WASHER-shoulder LM-16075-85 X X 1
14 WASHER-Belleville LM-16035-92 X X 1
15 SCREW-hex hd. cap, 5/16-18 x 3/4 LM-09173-97 X X 18
16 WASHER-lock, 5/16 LM-09173-56 X X 18
17 WASHER-Hat, 5/16 LM-09176-42 X X 18
18 NUT-hex, 5/16-18 LM-09173-72 X X 18
19 BLADE-mower (42”) LM-16075-36 X 3
BLADE-mower (48”) LM-16073-69 X 3
SIDE ARBOR & HOUSING LM-16075-84 X X
2
Includes:
20 ARBOR TUBE ASSEMBLY LM-16022-59 X X 2
21 BEARING f LM-01082-02 X X 4
22 SPACER LM-16022-65 X X 2
23 ARBOR ASSEMBLY LM-16073-67 X X 2
24 WASHER-special LM-01084-72 X X 4
25 SHEAVE-mower spindle LM-16028-81 X X 2
26 KEY-woodruff LM-09183-12 X X 2
27 NUT-jam hex LM-16070-21 X X 2
28 SCREW-hex cap, 7/16-20 x 1-1/2 LM-09280-66 X X 2
29 WASHER-lock, 7/16 LM-09181-99 X X 2
30 WASHER-shoulder LM-16075-85 X X 2
31 WASHER-belleville LM-16035-92 X X 2
32 STUD LM-16041-37 X X 1
33 WASHER-flat LM-09226-11 X X 2
34 WASHER-lock LM-09169-65 X X 2
35 NUT-hex LM-09169-50 X X 2
36 LEVER ASSEMBLY-idler LM-16030-88 X X 1
37 WASHER-flat LM-09249-40 X X 4
38 NUT-hex lock LM-09180-06 X X 1
39 PULLEY-idler LM-16035-15 X X 1
40 SPACER LM-16104-04 X X 1
41 SCREW-hex hd. cap, 3/8-16 x 1-3/4 LM-09193-61 X X 1
42 SPRING LM-16015-13 X X , 1
43 V-BELT ARBOR DRIVE LM-16030-77 X
1
V-BELT ARBOR DRIVE LM-16030-75 X 1
44 CLIP-spring LM-16030-90 X X 1
45 BELT-front, PTO drive LM-16072-84 X 1
BELT-front. PTO drive LM-01085-08 X 1
ALWAYS FURNISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
