Table 6—Heating Check Chart
(HIGH PRESSURE AT !
HEATING OPERATION PRESSURE TABLE, FIXED RESTRICTOR
Unit
38QRA
Indoor D
17
Bulb
Temp (F)
Outdoor Temperature (F) Dry Bulb
60
50
40
30
20
10
0
018
60
High
231.0
208.3
185.6
174.2
162.8
151.4
140.0
Low
80.4
70.6
60.8
53.7
46.6
39.5
32.4
Suction
66.8
57.9
49.0
42.9
36.8
30.7
24.6
70
High
257.0
231.6
206.1
194.1
182.1
170.0
158.0
Low
84.5
73.2
61.9
54.4
46.8
39.3
31.7
Suction
70.5
60.0
49.5
43.2
36.8
30.5
24.1
80
High
288.0
260.0
232.0
218.8
205.5
192.3
179.0
Low
87.6
75.6
63.6
55.6
47.6
39.6
31.6
Suction
73.4
62.5
51.6
44.7
37.9
31.0
24.1
024
60
High
226.9
203.2
179.4
155.0
148.2
141.5
134.5
Low
79.1
67.8
56.5
44.9
40.0
35.2
30.2
Suction
67.2
56.9
46.7
36.1
31.9 ,
27.7
23.4
70
High
254.2
222.1
189.9
156.8
155.3
153.8
152.3
Low
83.1
65.8
48.5
30.6
29.6
28.6
27.5
Suction
70.7
55.1
39.5
23.4
22.7
21.9
21.2
80
High
279.9
251.3
222.6
193.1
153.7
114.4
73.8
Low
85.7
70.9
56.2
41.0
36.5
32.1
27.5
Suction
72.7
59.4
46.2
32.5
28.8
25.1
21.4
030
60
High
157.7
151.3
144.9
138.3
132.2
126.0
119.7
Low
64.9
58.9
53.0
46.8
40.1
33.4
26.5
Suction
48.2
43.1
37.9
32.6
27.3
22.0
16.5
70
High
186.6
177.5
168.4
159.0
153.4
147.8
142.1
Low
70.0
62.1
54.2
46.0
40.4
34.7
28.9
Suction
52.7
45.8
38.9
31.8
27.4
23.0
18.4
80
High
216.0
205.3
194.7
183.7
177.4
171.2
164.7
Low
74.5
65.0
55.6
45.8
39.9
34.1
28.0
Suction
56.2
48.0
39.9
31.5
26.9
22.3
17.6
036 1 Phase
60
High
226.1
219.6
213.0
206.3
183.0
159.6
135.6
Low
117.7
110.8
103.9
96.8
84.6
72.4
59.8
Suction
65.3
55.4
45.6
35.4
30.2
25.0
19.6
70
High
252.0
230.3
208.5
186.1
177.2
168.3
159.1
Low
130.2
118.3
106.4
94.2
85.3
76.4
67.3
Suction
65.8
56.5
47.3
37.7
32.2
26.6
20.9
80
High
282.3
241.3
200.3
158.0
167.5
177.0
186.8
Low
144.8
121.4
97.9
73.8
74.8
75.8
76.9
Suction
67.3
56.9
46.4
35.7
31.5
27.3
23.0
036 3 Phase
60
High
193.7
180.4
167.0
153.3
145.8
138.3
130.6
Low
71.4
64.4
57.5
50.3
42.1
33.9
25.5
Suction
58.1
52.3
46.6
40.6
33.6
26.7
19.5
70
High
227.8
200.1
172.4
143.9
144.9
145.8
146.8
Low
79.7
94.6
109.5
124.9
92.4
59.8
26.3
Suction
65.7
61.1
56.6
51.9
41.4
30.8
20.0
80
High
235.4
222.6
209.9
196.7
187.5
178.4
168.9
Low
106.7
88.3
69.9
50.9
42.9
34.9
26.7
Suction
72.7
62.9
53.0
42.9
35.5
28.1
20.5
