1-Port G.SHDSL WAN Interface Card for Cisco 2600 Series Routers
Configuration Examples
9
Cisco IOS Release 12.2(4)XL
Configuration Examples
This section provides the following configuration examples:
• Configuration in CPE Mode Example
• Configuration in CO Mode Example
Configuration in CPE Mode Example
The following example shows a G.SHDSL configuration of VoATM over AAL2, operating in customer
premises equipment (CPE) mode, on a Cisco 2600 series router. This router in CPE mode can be linked
to either a DSLAM or to another router that is configured to operate in central office (CO) mode.
Router#
version 12.2
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname host1
!
memory-size iomem 10
voice-card 1
!
ip subnet-zero
ip host host2 225.255.255.224
!
no mgcp timer receive-rtcp
call rsvp-sync
!
!
controller T1 1/0
framing esf
linecode b8zs
ds0-group 0 timeslots 1 type e&m-wink-start
ds0-group 1 timeslots 2 type e&m-wink-start
.
.
.
ds0-group 23 timeslots 24 type e&m-wink-start
!
controller T1 1/1
framing esf
linecode b8zs
!
interface Ethernet0/0
ip address 209.165.202.128 255.255.255.224
half-duplex
no cdp enable
!
interface Serial0/0
no ip address
shutdown
!
interface ATM0/1
ip address 209.165.201.1 255.255.255.224
dsl operating-mode gshdsl symmetric annex A
dsl equipment-type cpe
dsl linerate auto
load-interval 30
