□l

How

TO U

se

the

P

icture

-I

n

-P

icture

(PIP)

F

eature

P

icture in Picture (PIP) is the

showing of two pictures on

the TV screen at the same time.
(One main screen picture and

one small inset picture - or PIP).

NOTE: The PIP picture must be
supplied by a VCR (or other
accessory equipped with a

VIDEO OUTPUT jack). See the

following example on how a VCR

can be used to supply a PIP pic­
ture.

(BEGIN)

Connect the VIDEO OUT

jack on the VCR to the VIDEO

IN jack on the TV.

Also connect the AUDIO OUT

jack (Right/Left) from the VCR

to the AUDIO IN jack on the TV.
(See Reminder note below.)

Also ensure the normal antenna
connection between the VCR and
TV is in place.

Move to the next page after

the VCR to TV PIP connections
are completed.

continue to next page

MAIN

SCREEN

PIP

WINDOW

BACK OF TV

VIDEO IN

(YELLOW)

RFANTENNA

CABLE

(SUPPLIED WITH

VCR)

VCR

(EQUIPPED WITH VIDEO AND

AUDIO OUTPUT JACKS)

\ I /

S

mart

H

elp

For other possible PIP

■ connections see page for the

“More PIP Connections” section.

If you have a single (monaural)
Audio Output VCR, “Y” connec­
tors are available to complete
your connection to the TV.
Contact your dealer, or our Parts
Information Center (1-800-292-
6066), for details.

30
