Compaq DA-10832 - Manual (Page 11)

QuickSpecs
Compaq iPAQ Desktop
DA-10832 North America — Version 8 — September 14, 2001 11
Technical Specifications
Environmental Operating Temperature 50 ° to 122 ° F/10 ° to 50 ° C Compaq 2-Button Scroll Mouse
Non-operating Temperature –22 ° to 140 ° F/–30 ° to 60 ° C
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40g, 6 surfaces
Non-operating Shock 80g, 6 surfaces
Operating Vibration 2g peak acceleration
Non-operating Vibration 4g peak acceleration
Drop (Out of Box) 26 in/660 mm on carpet, 6 drop sequence
Drop (Out of Box) One meter on asphalt tile over concrete,
6 drop sequence
Electrical Operating Voltage + 5VDC ± 10%
Power Consumption 15mA
System Consumption PS/2 mini-din connector
ESD CE level 4, 15kV air discharge
EMI-RFI Conforms to FCC rules for a Class B computing
device
PC98 Functionally compliant
Mechanical Resolution 400 ± 20% DPI
Tracking Speed 10 in/s Maximum
Acceleration 100 in/s/s
Switch Actuation 75 gram nominal peak force
Switch Life 1,000,000 operations (using Hasco modified
tester)
Switch Type Micro-switches
Tracking Mechanism Life 155 miles/250 km at average speed of 10 in/s
Cable Length 6 in/1.8 m
PC98-99 Mechanically compliant
Scroll Wheel Width 8 mm
Maximum Rotation Speed 30 mm/s
Switch Type Light force micro-switch
Switch Life 1 million operations
Mechanical Life Minimum 200,000 revolutions
Regulatory Approvals Compliant UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI,
BSMI, C-Tick
